TRACO POWER TEN32423 Dual-output DC/DC Converter
The TEN 3-2423 is a dual-output, board-mount isolated DC/DC converter with an input voltage range of 18 to 36 VDC. It delivers 82% efficiency and operates reliably from -40°C to +85°C. Designed with full SMD technology, it provides 1500 VDC input/output isolation and includes protections against overvoltage and short circuit. Ideal for industrial and communication systems, it supports up to 1000µF capacitive load, features a 300kHz switching frequency, and maintains excellent regulation with a temperature coefficient of ±0.02%/K, ensuring stable power in demanding environments.
TRACO POWER TEN32423 Dual-output DC/DC Converter Specifications:
- Input Voltage Range: 18-36 VDC
- Output Voltage: 5 V / 15 V
- Output Current Max: 250 mA / 200 mA
- Efficiency: 82%
- Isolation Voltage: 1500 VDC
- Maximum Capacitive Load: 1000 µF
- Switching Frequency: 300 kHz
- Temperature Range: -40°C to +85°C
- Temperature Coefficient: ±0.02%/K
- Protection: Overvoltage, Short Circuit
- Full SMD Design for High Reliability
- MTBF: >1.1 million hours
- Monitoring: Input/Output Regulation within 0.5%
- Ripple and Noise: 60 mVpk-pk
- Humidity: Up to 95% RH non-condensing
- Compliance: UL 60950-1, IEC/EN 60950-1, RoHS, Reach
Buy the Buy TracoPower DC/DC Converter Part Number TEN32423 Online
Enhance your industrial and communication systems with the reliable TracoPower TEN 3-2423 dual-output isolated DC/DC converter. Featuring input voltage 18-36 VDC, 82% efficiency, 1500 VDC input/output isolation, and a broad operating temperature range from -40°C to +85°C, this converter ensures stable power delivery. Its full SMD design guarantees high reliability and resistance to harsh environments. Perfect for networking, automation, and instrumentation applications, it supports capacitive loads up to 1000 µF and maintains excellent regulation under varying conditions. Purchase online now for quick, dependable power solutions.
Order your TracoPower SeriesTEN32423 high-efficiency dual-output isolated converter today and ensure reliable power supply for industrial and communication projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32423?
You can click on the BUY or RFQ button to purchase TEN32423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32423?
You can download the TEN32423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32423?
TRACO POWER
