TRACO POWER THD102422WIN DC-DC Converter
The THD 10-2422WIN from TracoPower is a 10W DC-DC converter in a 24-pin DIP package, part of the THD 10WIN series designed for optimized cost-performance. It features an internal EMI filter that complies with EN55022 Class A without external components. The converter supports an input voltage range from 9V to 36V (nominal 24V), with an output of ±12VDC and a maximum output current of ±416mA. It offers high efficiency around 87%, with no minimum load requirement, overload protection, and high reliability. The device provides 1500VDC isolation with a typical isolation capacitance of 1000pF and resistance greater than 1000 MΩ at 500VDC. It operates over a temperature range from -40°C to +85°C and is certified under UL/cUL 60950-1 and IEC/EN 60950-1 safety standards. Its ultra-wide 4:1 input voltage range and standard DIP-24 package make it suitable for industrial, communication, and networking applications, providing a reliable, drop-in solution for cost-critical designs.
TRACO POWER THD102422WIN DC-DC Converter Specifications:
- Power: 10 Watts
- Input voltage range: 9V to 36V
- Output voltage: ±12 VDC
- Output current: 416 mA max
- Efficiency: up to 87%
- Isolation voltage: 1500 VDC
- Isolation capacitance: 1000 pF typ.
- Isolation resistance: >1000 MΩ at 500VDC
- Operating temperature: -40°C to +85°C
- Case material: Metal with non-conductive baseplate
- Dimensions: Standard DIP-24 package
- Safety standards: UL/cUL 60950-1, IEC/EN 60950-1
- Soldering temperature: Max 260°C for 10 sec.
- Humidity (non condensing): 95%
- Reliability: MTBF 1,000,000 hours
- Pin pitch: 2.54 mm
- Remote On/Off control: 3.5 to 12 VDC or open circuit
Buy the TracoPower Series THD 10WIN DC-DC Converter: THD102422WIN
Order the TracoPower THD102422WIN DC-DC converter online today and benefit from its robust design, high efficiency of up to 87%, and wide input voltage range. Ideal for industrial, communication, and networking applications, this 10W device offers isolation of 1500VDC, UL/cUL and IEC safety certifications, and operates reliably within a temperature range of -40°C to +85°C. Its DIP-24 package ensures easy integration, while overload protection and no minimum load requirements make it a versatile, cost-effective solution for demanding electronic projects. Purchase now to enhance your system’s reliability and performance.
Get TracoPower THD102422WIN today—built for industrial reliability and high efficiency.
Frequently Asked Questions
Where can I buy TRACO POWER THD102422WIN?
You can click on the BUY or RFQ button to purchase THD102422WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD102422WIN?
You can download the THD102422WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD102422WIN?
TRACO POWER
