TRACO POWER THN301212 DC/DC Converter Module
The THN 30 series offers high-performance 30W DC/DC converters in a compact 1.0 x 1.0 x 0.4-inch metal case, featuring wide input voltage ranges, high efficiency up to 92%, and operating temperatures from -40°C to +85°C with heat-sinks. These reliable modules include features like over-temperature protection, remote On/Off control, low no-load input current, and 1500 VDC input/output isolation, making them ideal for space-constrained industrial, communication, and battery-operated applications requiring precise, regulated output voltages under harsh conditions.
TRACO POWER THN301212 DC/DC Converter Module Specifications:
- Dimensions: 1.0 x 1.0 x 0.4 inches (25.4 x 25.4 x 10.16 mm)
- Output Power: 30 Watts
- Input Voltage Range: Wide 2:1 ratio (e.g., 9-18 VDC, 18-36 VDC, 36-75 VDC)
- Output Voltage: 3.3 VDC, 5 VDC, 9-18 VDC, 12 VDC, 15 VDC, 24 VDC, +12 VDC, +15 VDC, 36-75 VDC nominal
- Maximum Output Current: 7000 mA (for 3.3V), 6000 mA (for 5V), 2500 mA (for 12V, 15V, 24V)
- Efficiency: Up to 92% across load range
- Operating Temperature: -40°C to +85°C with heat-sink, -40°C to +80°C without
- Isolation Voltage: 1500 VDC input/output, 1000 VDC input/case
- Input Current at No Load: 8-12 mA depending on model
- Surge Voltage: Up to 100 V max
- Switching Frequency: 275-330 kHz
- Protection: Over-temperature, short circuit, over-voltage
- Compliance: UL 60950-1, IEC 60950-1, RoHS 2011/65/EU
- Weight: Approximately 16.5 grams
- Environmental: Non-condensing humidity 5–95%, thermal shutdown at 115°C, thermal impedance 13.8°C/W with heat-sink
Buy the Traco Power THN 30 Series – Reliable DC Power Modules for Industrial Applications
Purchase the Traco Power THN 30 series online today to ensure your system benefits from reliable, high-efficiency DC/DC conversion. With compact size, wide input voltage range, and robust thermal performance, these converters are ideal for industrial electronics, communication equipment, and battery-powered systems where space, efficiency, and durability are critical. Enjoy easy integration, excellent regulation, and long-term reliability by acquiring these proven modules online—designed for professionals who demand top-quality power solutions for complex applications.
Get Traco Power THN 30 series today—compact, high-efficiency converters built for demanding industrial and communication systems.
