TRACO POWER TRN30515 DC/DC Converter
The TRACO POWER TRN 3 Series is a compact 3-watt DC/DC converter module designed for space-constrained applications. Featuring fully regulated outputs, high efficiency, and broad input voltage ranges from 4.5V to 75V, it provides robust performance with an isolation voltage of 1600 VDC. Its miniature SIP package measures 11.9 x 7.7 x 11.0 mm, operates reliably from -40°C to +85°C, and includes short circuit protection. Suitable for various industrial and automation systems, it meets UL 62368-1 and IEC/EN 62368-1 safety standards for versatile deployment.
TRACO POWER TRN30515 DC/DC Converter Specifications:
- Input Voltage Range: 4.5-13.2, 9-18, 18-36, 36-75 VDC
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V, 36V, 48V
- Maximum Output Current: up to 700mA
- Isolation Voltage: 1600 VDC
- Dimensions: 11.9 x 7.7 x 11.0 mm
- Operating Temperature Range: -40°C to +85°C
- Efficiency: 75% to 84%
- Short Circuit Protection: Yes
- Input Current No Load: 12-75 mA depending on model
- Ripple and Noise: 50 mVp-p typical
- MTBF: 4,400,000 hours
- Soldering Temperature: 260°C for 6 seconds
- Case Material: Non-conductive black plastic
- Potting Material: Silicone (UL 94-V0 rated)
Buy the Traco Power Series TRN 3 DC/DC Converter: TRN30515
Discover the high-performance Traco Power TRN 3 Series 3W DC/DC converter, offering fully regulated outputs, wide input voltage ranges, high isolation voltage of 1600 VDC, compact SIP package measuring 11.9 x 7.7 x 11.0 mm, and reliable operation from -40°C to +85°C. Its efficiency ranges from 75% to 84%, providing robust power solutions for industrial, automation, and electronic applications. Short circuit protection and compliance with UL 62368-1 safety standards ensure safety and durability for versatile deployment in space-constrained environments.
Buy Traco Power TRN30515 now and experience unmatched reliability and compact design for your power conversion needs.
Frequently Asked Questions
Where can I buy TRACO POWER TRN30515?
You can click on the BUY or RFQ button to purchase TRN30515 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TRN30515?
You can download the TRN30515 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TRN30515?
TRACO POWER
