TRACO POWER TMLM04115 Power Module
The TMLM series power modules provide high-density AC/DC conversion in a fully encapsulated design, ideal for space-constrained industrial and commercial electronics. They support universal input 90-264 VAC, deliver power from 4 to 20 Watts with efficiencies up to 83%, and comply with international safety and EMC standards including UL 60950-1 and EN 55022. Features include low ripple, noise, short circuit and overload protection, and an operating temperature range of 25°C to +60°C, making them reliable for various industrial applications.
TRACO POWER TMLM04115 Power Module Specifications:
- Power Output: 4 to 20 Watts
- Input Voltage: 90-264 VAC, 47-440 Hz
- Output Voltage: 3.3V / 5V / 9V / 12V / 15V / 24V (varies by model)
- Efficiency: Up to 83%
- Ripple & Noise: <250mV to <480mV (varies by model)
- Input Current: 70-385 mA (full load)
- Inrush Current: Max 20-40 A
- Operating Temperature: 25°C to +60°C, derating above +40°C
- Isolation Voltage: 3000 VAC
- Dimensions & Weight: Varies (26g to 59g per model)
- Certification: UL 60950-1, EN 55022, RoHS, Reach
- Protection: Short circuit, overload, overvoltage
- Switching Frequency: 132 ±8 kHz
- Humidity: Up to 95% RH (non-condensing)
Buy the TracoPower TMLM04115 – Reliable Power Modules for Industrial Applications
Purchase the TracoPower TMLM04115 power module online and ensure your industrial equipment operates reliably with high efficiency, low noise, and compact size. These fully encapsulated modules support universal input, offer multiple output options, and comply with international safety standards, making them suitable for various automation and control systems. With features like overload protection, low ripple, and EMI compliance, purchasing online guarantees quick delivery, secure transaction, and access to genuine products engineered for durability and long-term performance in critical environments.
Get TracoPower TMLM04115 today—built for industrial reliability and space-saving performance.
Frequently Asked Questions
Where can I buy TRACO POWER TMLM04115?
You can click on the BUY or RFQ button to purchase TMLM04115 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMLM04115?
You can download the TMLM04115 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMLM04115?
TRACO POWER
