TRACO POWER THN152415WIR Power Converter
The THN 15WIR series combines rugged durability and high efficiency in a compact 1”x1”x0.4” package, providing 15 Watt DC/DC power conversion for harsh environments. It features ultra-wide input voltage ranges of 9-36V, 18-75V, and 36-160V DC, with up to 91% efficiency, remote On/Off, output voltage trim, and built-in EMC filter. Certified for railway and transportation applications under EN 50155 and EN 61373 standards, it also complies with EN 45545-2 fire safety and IEC/EN 60950-1 safety standards, ensuring reliable performance in demanding industrial environments.
TRACO POWER THN152415WIR Power Converter Specifications:
- Output Power: 15 Watt
- Input Voltage Range: 9-36 VDC, 18-75VDC, 36-160 VDC
- Efficiency: Up to 91%
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, 24 V, ±5 V, ±12 V, ±15 V, ±24 V
- Output Current: 1000 mA to 4500 mA depending on model
- Input Current (no load): 10-12 mA typical
- Operating Temperature: -40°C to +90°C (derating above 75°C)
- Isolation Voltage: 3000 VDC input to output
- Dimensions: 25.4 x 25.4 x 10.2 mm
- Protection Features: Under-voltage lockout, short circuit, overvoltage
- EMC Standards: EN 55032, EN 61000-4 series
- Safety Standards: IEC/EN 60950-1, UL60950-1
- Compliance: EN 50155, EN 61373, EN 45545-2 fire safety
- Construction: Copper case, FR4 PCB, UL94 V-0 silicone potting
- Certifications: UL, RoHS, REACH
Buy the Traco Power Series THN 15WIR DC/DC Converter: THN152415WIR
Purchase the Traco Power Series THN 15WIR DC/DC converter online to enjoy high efficiency, rugged design, and certified safety for demanding industrial and transportation applications. Compact and lightweight, with wide input voltage range and advanced features like remote On/Off, output trim, and robust EMC filtering, it guarantees reliable operation under extreme conditions. Perfect for railway, automation, and harsh environment systems, this converter ensures your power needs are met with optimal performance and compliance with global safety standards. Order now for dependable power in your critical projects.
Order your Traco Power Series THN 15WIR DC/DC Converter today and ensure your industrial projects benefit from high-quality and reliable power solutions.
