TRACO POWER TPP15105D Medical Power Supply
The TPP 15-D Series is a compact, high-efficiency 15-watt medical power supply designed for healthcare devices and equipment. It complies with IEC/EN/ES 60601-1 3rd edition for 2 x MOPP safety standards, ensuring patient protection with reinforced isolation and low leakage current below 75 μA. Suitable for BF applications, it operates at altitudes up to 5000 meters, features a wide input range of 85-264 VAC, and offers excellent electromagnetic compatibility. Its full load temperature range is from -40°C to +70°C, with up to 88.5% efficiency and comprehensive safety and EMC certifications.
TRACO POWER TPP15105D Medical Power Supply Specifications:
- Input Voltage: 85-264 VAC, 120-370 VDC
- Input Frequency: 47-63 Hz
- Output Power: 15W
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, 48V (adjustable ±10%)
- Output Current: 4A (3.3V), 3A (5V), 1.67A (9V), 1.26A (12V), 1A (15V), 0.625A (24V), 0.417A (36V), 0.313A (48V)
- Efficiency: up to 89%
- Operating Temperature: -40°C to +70°C, up to 85°C with 50% load derating
- Power Derating: 4%/V below 90V input voltage
- Protection Class: II, Reinforced Insulation
- Leakage Current: <75 μA at 264 VAC
- Isolation Voltage: input to output 5600 VDC, input to case 21121 VDC, output to case 21121 VDC
- Dimensions: 21.5 mm x 42.0 mm x 30 mm
- Weight: 43g
- Certification: IEC 60601-1, IEC 62368-1, UL 62368-1, EN 60601-1
- EMC Standards: EN 55011/14/32, FCC Part 15/18, EN 61000-3-2/3
- Environmental: Operating at altitudes up to 5000m, humidity up to 95% non-condensing
Buy the Traco Series TPP 15-D Medical Power Supply: TPP15105D
Order the Traco Series TPP 15-D medical power supply online today to ensure your healthcare devices operate safely and efficiently. This 15-watt unit features reinforced safety isolation, low leakage current, and high efficiency up to 89%, making it ideal for patient-critical BF applications. With a compact size, wide input range (85-264 VAC), and certification according to IEC 60601-1 and IEC 62368-1 standards, it guarantees reliable performance in demanding medical environments. Invest in proven quality for your medical equipment now.
Buy Traco Series TPP 15-D medical power supply now and experience unmatched reliability and high efficiency in healthcare applications.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15105D?
You can click on the BUY or RFQ button to purchase TPP15105D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15105D?
You can download the TPP15105D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15105D?
TRACO POWER
