TRACO POWER TEL101211 DC/DC Converter
The TEL 10 Series offers a compact 10-watt DC/DC converter in a DIP-16 metal casing designed for space-critical applications. With a wide 2:1 input voltage range, high efficiency up to 88%, and low thermal dissipation, it is suitable for instrumentation, industrial electronics, and IT projects. It features built-in filters for conducted emissions, automatic short circuit recovery, and operates in temperatures from -40°C to +88°C. Its robust construction and certifications make it ideal for reliable, high-density power conversion in demanding environments.
TRACO POWER TEL101211 DC/DC Converter Specifications:
- Input Voltage Range: 9-48 VDC
- Input Current: At full load 12 V: 970 mA, 24 V: 480 mA, 48 V: 240 mA
- Surge Voltage: 72 VDC max. (1 s max) for 72 V models, 60 VDC max. (1 s) for 24 V models, 100 VDC for 48 V models
- Output Power: 10 Watts
- Efficiency: Up to 88%
- Operating Temperature Range: -40°C to +88°C
- Isolation Voltage: 1800 VDC (input to output), 707 VAC (input/output to case)
- Ripple & Noise: 60-96 mVp-p depending on model
- Capacitive Load: Up to 2600 pF for 3.3V output, smaller for higher voltages
- Start-up Time: 30 ms typical
- Protection: Short circuit, automatic recovery, output current limitation 192% of max load
- Housing: Aluminum alloy, epoxy potting, tinned copper pins
- Certifications: UL 62368-1, IEC 62368-1, EN 55032 Class A emission compliance
- Insulation: Functional insulation, test voltage 1800 VDC
Buy the Traco Power Series TEL 10 DC/DC Converter: TEL101211
Enhance your power management with the Traco Power TEL 10 Series 10 Watt DC/DC converter. Featuring a compact DIP-16 metal case, it delivers high efficiency up to 88% and operates across a wide input voltage range from 9 to 48V. Its robust construction ensures dependable performance in demanding environments with operating temperatures from -40°C to +88°C. It is certified UL, IEC, and EN standards, with built-in filters for conducted emissions, automatic short circuit protection, and a quick start-up time. Perfect for industrial, instrumentation, and IT applications where space and reliability are critical, order online today for an economical, high-density power solution.
Order your Traco Power Series TEL 10 DC/DC Converter today and ensure efficient, reliable power supply for your industrial and electronic projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEL101211?
You can click on the BUY or RFQ button to purchase TEL101211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL101211?
You can download the TEL101211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL101211?
TRACO POWER
