TRIAD MAGNETICS WSU050400013 Power Supply
The WSU050-4000-13 from Triad Magnetics is a compact switch-mode power supply providing a stable 5V DC output with a maximum of 4A current, delivering up to 20W of power. It covers input voltage ranges from 100VAC to 240VAC, suitable for worldwide use, and features a thermoplastic enclosure for heat management and noise reduction. Fully enclosed for safety, it complies with Level VI efficiency standards and UL 60950-1, CSA, and RoHS regulations. Includes an 18 AWG, 5-foot output cord, and has dimensions optimized for space-saving industrial and power management applications. Operating temperature ranges from 0°C to +40°C, making it reliable for continuous operation in various environments.
TRIAD MAGNETICS WSU050400013 Power Supply Specifications:
- Input Voltage Range: 100-240VAC, 50-60Hz
- Output Voltage: 5VDC
- Output Current: 4.0A
- Power Output: 20W
- Efficiency: Level VI minimum, 283.08%
- Dielectric Strength: 4KVDC for 60 seconds
- Enclosure: Thermoplastic molded, compact size
- Output Cord: 18 AWG, 5 feet long
- Output connector: Inner diameter 2.5mm, outer diameter 5.5mm, length 11mm
- Operating Temperature: 0°C to +40°C
- Storage Temperature: -20°C to 60°C
- Certifications: UL 60950-1, CSA, RoHS, FCC Part 15 Class B
- Safety: Over voltage, short circuit protected
- Environment: Humidity 5% to 95%, Non-condensing
- Warranty: 5 years
Buy the Buy Triad Power Supply Part Number WSU050400013 Online
Purchase the Triad WSU050-4000-13 power supply online today. This reliable, UL and CSA certified unit provides a stable 5V DC output with 4A current, suitable for industrial applications. Its compact thermoplastic enclosure ensures effective heat management and durability. With a wide input voltage range of 100-240VAC, it supports global use, meeting Level VI efficiency standards for energy savings. The included 18 AWG, 5-foot output cord, and safety features make it ideal for power management in various environments. Order now for quick delivery and long-lasting performance.
Get Triad Power Supply WSU050-4000-13 today—built for reliable power delivery and safety in industrial, automation, and power management applications.
Frequently Asked Questions
Where can I buy TRIAD MAGNETICS WSU050400013?
You can click on the BUY or RFQ button to purchase WSU050400013 from an authorized TRIAD MAGNETICS distributor.
How do I troubleshoot issues or seek technical support for part WSU050400013?
You can download the WSU050400013 datasheet or visit the TRIAD MAGNETICS website for support.
Who is the manufacturer of WSU050400013?
TRIAD MAGNETICS
