TTElectronics - Welwyn LRMAP5930CR002FT Power Resistor
The LRMAP5930 series low resistance power resistors are made from metal alloy for high stability and performance in current sensing applications for power electronics. Featuring resistance ranges from 0.2 milliohm to 2 milliohm, they deliver up to 15W power rating, excel in long-term stability, and are suitable for high-temperature environments from -55°C to 170°C. These Pb-free, RoHS3-compliant resistors are designed for reliable automatic insertion and PCB mounting, with verified thermal, pulse, and overload performance, making them ideal for industrial and automotive electronics.
TTElectronics - Welwyn LRMAP5930CR002FT Power Resistor Specifications:
- Resistance Range: 0.2mΩ to 2mΩ
- Power Rating: Up to 15W
- Temperature Range: -55°C to 170°C
- Resistance Tolerance: ±1%
- Resistance Coefficient (TCR): +100 to +475 ppm/°C
- Peak Pulse Power: 50W for 5s
- Continuous Pulse Energy: up to 75J
- Material: Metal alloy, EBW resistive strip
- Dimensions vary with model, typical length around 1.42mm to 50mm
- Mounting: On FR4 board or thermal substrate, with laser marking
- Injected in tape packaging, 2000 pieces per reel
- Certifications: RoHS3, Pb-free, complies with EU Directive 2011/65/EU
- Soldering Profile: Pre-heat at 180°C for 30-45s, peak at 260°C for 20-40s
Buy the Buy TT Electronics LRMAP5930 Power Resistors Part Number LRMAP5930CR002FT Online
Purchase the LRMAP5930 series power resistors online and ensure reliable current sensing for your power electronics projects. These low resistance, high stability resistors feature up to 15W power rating, excellent temperature performance from -55°C to 170°C, and are RoHS3 compliant and Pb-free. Designed for PCB mounting and automation, they offer excellent pulse and overload stability, making them perfect for industrial applications. Get high-precision, durable resistors with fast delivery and expert support by buying online today.
Buy TT Electronics LRMAP5930 resistor now and experience unmatched reliability and high current sensing performance for industrial and automotive electronics.
Frequently Asked Questions
Where can I buy TTElectronics - Welwyn LRMAP5930CR002FT?
You can click on the BUY or RFQ button to purchase LRMAP5930CR002FT from an authorized TTElectronics - Welwyn distributor.
How do I troubleshoot issues or seek technical support for part LRMAP5930CR002FT?
You can download the LRMAP5930CR002FT datasheet or visit the TTElectronics - Welwyn website for support.
Who is the manufacturer of LRMAP5930CR002FT?
TTElectronics - Welwyn
