Vishay BFC233841106 Interference Suppression Film Capacitor
The Vishay MKP338 4 X2 interference suppression film capacitor is designed for across the line applications with a rated voltage of 300 Vac and heat resistance up to 105°C. Constructed with metallized polypropylene film, it features self-healing properties, flame-retardant epoxy resin sealing (UL class V-0), and various lead pitch options from 15 mm to 55 mm. Suitable for EMI filtering and interference suppression in electronic circuits, the capacitor complies with IEC 60384-14 and EN60384-14 standards, and is RoHS and Halogen-Free certified, ensuring safety and environmental compliance.
Vishay BFC233841106 Interference Suppression Film Capacitor Specifications:
- Capacitance range: 0.01 UF to 10 UF
- Rated AC voltage: 300 Vac, 50/60 Hz
- Permissible DC voltage: 800 Vpc at 85°C, 630 Vdc at 110°C
- Temperature rating: 105°C
- Dielectric: Polypropylene film
- Construction: Metallized film, mono construction
- Sealing: Plastic case, epoxy resin sealed, UL V-0 flame retardant
- Lead pitch options: 15 mm, 22.5 mm, 27.5 mm, 37.5 mm, 55 mm
- Lead lengths: 3.5 mm, 5.0 mm, 25.0 mm with tolerance ±0.3 mm
- Standards: IEC 60384-14, EN60384-14, UL 60384-14
- RoHS and Halogen-Free compliant
- Climatic category: 55/105/56 (IEC 60068-1)
- Dimensions: Vary according to pitch and lead length, typical diameters around 0.6 to 1.0 mm
- Features: Self-healing, flame retardant, RoHS compliant
Buy the Buy Vishay MKP338 4 X2 Part Number BFC233841106 Online
Purchase the Vishay MKP338 4 X2 interference suppression film capacitor online today to ensure high-performance EMI filtering and interference suppression. Designed with metallized polypropylene film, it offers reliable self-healing properties, flame-retardant sealed construction, and versatile lead pitch options, making it ideal for across-the-line applications. With rated voltages up to 300 Vac and temperature resistance of 105°C, this capacitor meets international safety standards, RoHS, and Halogen-Free certifications, providing safety, durability, and environmental compliance for your electronic projects.
Get Vishay MKP338 4 X2 today—built for interference suppression and long-lasting durability in electronic circuits.
Frequently Asked Questions
Where can I buy Vishay BFC233841106?
You can click on the BUY or RFQ button to purchase BFC233841106 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part BFC233841106?
You can download the BFC233841106 datasheet or visit the Vishay website for support.
Who is the manufacturer of BFC233841106?
Vishay
