Vishay CRCW04026K80FKEDHP Thick Film Chip Resistor
The Vishay CRCW-HP e3 series represents a robust solution for power measurement electronics requiring reliability, stability, high power rating, and excellent pulse load performance. These thick film chip resistors are AEC-Q200 qualified and feature a double-side printed resistive element. Typical applications include battery management systems in automotive appliances. The resistors offer excellent pulse load capability and enhanced power rating, ensuring consistent performance under demanding conditions. They are available in various sizes and tolerances to meet diverse application needs.
Vishay CRCW04026K80FKEDHP Thick Film Chip Resistor Specifications:
- Description: CRCW0402-HP e3
- Imperial size: 0402
- Metric size code: RR1005M
- Resistance range: 1 Ω to 1 M Ω
- Resistance tolerance: ± 5 %; ± 1 %; ± 0.5 %
- Temperature coefficient: ± 200 ppm/K; ± 100 ppm/K
- Rated dissipation_P_70 (1): 0.2 W
- Operating voltage_U_max.ACRMS/DC: 50 V
- Permissible film temperature_F max. (1): 155 °C
- Operating temperature range: -55 °C to +155 °C
- Max. resistance change at_P_70for resistance range: ≤ 2.0 % after 1000 h; ≤ 4.0 % after 8000 h
- Permissible voltage against ambient insulation: 75 V
- Marking: See document “Surface Mount Resistor Marking”
- Application Information: When the resistor dissipates power, a temperature rise above the ambient temperature occurs, dependent on the thermal resistance of the assembled resistor together with the printed circuit board. The rated dissipation applies only if the permitted film temperature is not exceeded.
Buy the CRCW04026K80FKEDHP VISHAY Thick Film Chip Resistor | myMectronic
Purchase the Vishay CRCW04026K80FKEDHP Thick Film Chip Resistor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Vishay CRCW04026K80FKEDHP?
You can click on the BUY or RFQ button to purchase CRCW04026K80FKEDHP from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part CRCW04026K80FKEDHP?
You can download the CRCW04026K80FKEDHP datasheet or visit the Vishay website for support.
Who is the manufacturer of CRCW04026K80FKEDHP?
Vishay
