Vishay HVCC203Y6P221MEAX High Voltage Ceramic Capacitor
The Vishay HVCC Series high voltage ceramic capacitors are radial-leaded, single-layer disc components designed for high reliability in industrial, medical, and high-voltage power supply applications. Featuring ceramic class 2 dielectric Y6P with a temperature coefficient of +10% from -30°C to +105°C, they offer capacitance ranges from 100 pF to 2000 pF and voltage ratings up to 20,000 V. Constructed with silver-plated ceramic discs and tinned copper-steel leads, these RoHS-compliant capacitors withstand high dielectric strength, operate reliably over wide temperature ranges, and are ideal for use in X-ray sources, pulsed lasers, baggage scanners, and industrial lasers.
Vishay HVCC203Y6P221MEAX High Voltage Ceramic Capacitor Specifications:
- Ceramic class 2 dielectric Y6P with +10% temperature coefficient from -30°C to +105°C
- Capacitance range: 100 pF to 2000 pF
- Voltage (Uratea, ac): up to 7000 V depending on rated pulsating voltage
- Maximum dissipation factor: 1.5%
- Insulation resistance: minimum 200,000 MΩ at 500 V
- Maximum working temperature: +105°C, minimum -30°C
- Dimensions vary with capacitance; typical lead spacing 9.5 mm to 12.5 mm, lead diameter 0.65 mm to 0.8 mm
- Construction: Ceramic disc with silver-plated surfaces, tinned copper-clad steel leads
- Coating: Flame-retardant epoxy resin (UL 94 V-0)
- Maximum pulse voltage: 1.35 × Uratea, pc for 60 seconds
- Application: High voltage power supplies, X-ray equipment, pulsed lasers, industrial and medical applications
Buy the Buy Vishay HVCC Series High Voltage Ceramic Capacitor Part Number HVCC203Y6P221MEAX Online
Purchase the Vishay HVCC203Y6P221MEAX high voltage ceramic capacitor online today and ensure your high-voltage power supplies, X-ray systems, and pulsed lasers operate with unparalleled reliability. These capacitors feature a ceramic Y6P dielectric, high dielectric strength, and wide operating temperature range, making them ideal for demanding industrial, medical, and electronic applications. With radial leads, flame-retardant epoxy coating, and compliance with RoHS standards, they provide long-lasting durability, high capacitance up to 2 nF, and withstand voltage up to 20,000 V, delivering superior performance for your critical projects.
Get Vishay HVCC203Y6P221MEAX today—designed for high-voltage medical and industrial applications with reliable performance and robust build quality.
Frequently Asked Questions
Where can I buy Vishay HVCC203Y6P221MEAX?
You can click on the BUY or RFQ button to purchase HVCC203Y6P221MEAX from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part HVCC203Y6P221MEAX?
You can download the HVCC203Y6P221MEAX datasheet or visit the Vishay website for support.
Who is the manufacturer of HVCC203Y6P221MEAX?
Vishay
