Vishay M64P502KB40 Multi-Turn Cermet Trimmer
The Vishay Spectrol Model 64 is a compact 3/8 inch square multi-turn cermet trimmer designed for precise PCB adjustments. Featuring five variants, it offers excellent operational stability with a resistive cermet element, suitable for industrial applications demanding reliable, stable performance. It is RoHS compliant, rated for 0.5W at 70°C, and withstands temperature ranges from -55°C to +155°C. The trimmer's sealed design ensures IP67 protection, with electrically linear travel of approximately 23 turns and low contact resistance variation, making it ideal for precision tuning in electronic equipment.
Vishay M64P502KB40 Multi-Turn Cermet Trimmer Specifications:
- Resistive element: Cermet
- Electrical travel: 21 turns + 2
- Resistance range: 10 Ω to 2.2 MΩ
- Power rating: 0.5 W at +70°C
- Resistance tolerance: 10%, optional 5%
- Dielectric strength: 1000 V RMS
- Insulation resistance: > 10^8 Ω at 500 V
- Temperature range: -55°C to +155°C
- Sealing: Fully sealed, IP67
- Mechanical travel: 23 turns + 5
- Operating torque: Max 1.5 N·cm
- Terminals: Pure Sn (code E3)
- Climatic category: 55/125/56
- Weight: Approx. 0.82 g
Buy the Buy Vishay Spectrol Model 64 Part Number M64P502KB40 Online
Purchase the Vishay Spectrol Multi-Turn Cermet Trimmer online today to ensure precise, stable, and reliable resistance adjustments in your electronic projects. With sealed IP67 protection and a wide operating temperature range from -55°C to +155°C, this compact 3/8 inch square trimmer offers five available variants for optimal PCB mounting. Its low contact resistance variation and high stability make it ideal for industrial, automation, and sensitive instrumentation applications. Order now to benefit from quick delivery, competitive pricing, and trusted quality for your manufacturing needs.
Buy Vishay Spectrol Model 64 M64P502KB40 now and experience unmatched reliability and precision in multi-turn cermet trimmers.
Frequently Asked Questions
Where can I buy Vishay M64P502KB40?
You can click on the BUY or RFQ button to purchase M64P502KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64P502KB40?
You can download the M64P502KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64P502KB40?
Vishay
