Vishay M64W503KB40 Multi-Turn Cermet Trimmer
The Vishay Spectrol 3/8-inch square multi-turn cermet trimmer is designed for precise resistance adjustments in electronic circuits. With a compact 10 mm size, it features excellent stability thanks to its cermet element, rated for 0.5 W at +70°C, and conforms to RoHS standards. Suitable for industrial applications, it offers resistance ranges from 10 Ω to 2.2 MΩ, with a linear resistance characteristic and a dielectric strength of 1000 V. Fully sealed for environmental resistance, it supports a temperature range from -55°C to +155°C, ensuring reliable performance in demanding conditions. The device's mechanical travel is approximately 23 turns, with a maximum operating torque of 1.5 N·m, and it is equipped with pure Sn terminals, making it ideal for high-precision adjustments.
Vishay M64W503KB40 Multi-Turn Cermet Trimmer Specifications:
- Resistive element: Cermet
- Resistance range: 10 Ω to 2.2 MΩ
- Power rating: 0.5 W at +70°C
- Dielectric strength: 1000 V RMS
- Insulation resistance: 10^8 MΩ at 500 V
- Mechanical travel: Approximately 23 turns
- Maximum operating torque: 1.5 N·m
- Temperature range: -55°C to +155°C
- Sealing: Fully sealed, IP67
- Terminal material: Pure Sn
- Dimensions: 3/8 inch square (10 mm)
- Climatic category: 55/125/56
- Rated voltage: 250 V linear law
- Contact resistance variation: < 1%
- Tolerance: ±5%, ±10%
Buy the Vishay Series Spectrol Multi-Turn Cermet Trimmer: M64W503KB40
Purchase the Vishay Spectrol Multi-Turn Cermet Trimmer online today for high-precision resistance adjustments in your electronic applications. This compact, RoHS-compliant component features resistance ranges from 10 Ω to 2.2 MΩ, with a power rating of 0.5 W at +70°C and full IP67 sealing for environmental protection. Ideal for industrial, measurement, and control circuits, it offers excellent stability, a maximum of 23 turns, and a maximum torque of 1.5 N·m, ensuring reliable and accurate tuning in demanding conditions.
Order your Vishay Spectrol Series 3/8 inch multi-turn cermet trimmer today and give your projects the dependable quality they deserve for precise circuit adjustments.
Frequently Asked Questions
Where can I buy Vishay M64W503KB40?
You can click on the BUY or RFQ button to purchase M64W503KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64W503KB40?
You can download the M64W503KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64W503KB40?
Vishay
