Vishay M64Z503KB40 multi-turn cermet trimmer
The Vishay Spectrol Model 64 is a compact, industrial-grade multi-turn cermet trimmer designed for precise PCB adjustments. Measuring 3/8" x 3/8" x 3/16" with five version options, it features high stability, RoHS compliance, and tests according to IEC standards. The resistive element is a cermet, offering excellent operational stability. It offers resistance ranges from 10.9 to 2.2 MΩ with a power rating of 0.5 W at +70°C. Fully sealed IP67, it operates from -55°C to +125°C, making it suitable for diverse electronic applications requiring precise resistance adjustment.
Vishay M64Z503KB40 multi-turn cermet trimmer Specifications:
- Resistive element: Cermet
- Resistance range: 10.9 to 2.2 MΩ
- Power rating: 0.5 W at +70°C
- Tolerance: Standard 10%, on request 5%
- Temperature coefficient: as per standard resistance table
- Maximum voltage: 250 V linear law
- Operating temperature: -55°C to +125°C
- Mechanical travel: 23 turns ±5
- End resistance: 12 Ω (typical)
- Insulation resistance: > 10 MΩ at 600 Vdc
- Dielectric strength: 1000 V RMS
- Sealing: Fully sealed, IP67
- Wiper travel: approximately 50%
- Terminal material: Pure Sn (code 3)
- Weight: approx. 0.82 g
- Mechanical dimensions: 3/8" x 3/8" x 3/16"
- Climatic category: 55/125/56
Buy the Buy Vishay Spectrol Multi-Turn Cermet Trimmer Part Number M64Z503KB40 Online
Discover the high-quality Vishay Spectrol Series64 M64Z503KB40 multi-turn cermet trimmer, designed for precise resistance adjustment in electronic applications. Its compact size, robust IP67 sealing, and wide operating temperature range from -55°C to +125°C make it ideal for PCB and instrumentation uses. With resistance values up to 2.2 MΩ and a power rating of 0.5 W, this trimmer ensures stability, durability, and dependable performance. Buy online now for fast delivery and excellent technical support, perfect for manufacturing, repair, and calibration projects.
Order your Vishay Series64 M64Z503KB40 multi-turn cermet trimmer today and ensure precise, reliable resistance adjustments for your electronics projects.
Frequently Asked Questions
Where can I buy Vishay M64Z503KB40?
You can click on the BUY or RFQ button to purchase M64Z503KB40 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M64Z503KB40?
You can download the M64Z503KB40 datasheet or visit the Vishay website for support.
Who is the manufacturer of M64Z503KB40?
Vishay
