Vishay CRCW06035R60JNEAIF Pulse Resistor
The CRCW06035R60JNEAIF is a pulse-proof thick film chip resistor designed for high pulse performance up to 10 kW, with stability of AR/R less than 1% over 1000 hours at 70°C. Featuring RoHS compliance and AEC-Q200 qualification, this resistor offers a resistance of 5.60 ohms with a tolerance of 5% and a temperature coefficient of +200 ppm/K. Its compact 0603 case size ensures easy surface-mount integration suitable for demanding electronic applications requiring high pulse resilience and reliability.
Vishay CRCW06035R60JNEAIF Pulse Resistor Specifications:
- Resistance: 5.60 ohms
- Resistance Tolerance: ±5%
- Temperature Coefficient: +200 ppm/K
- Power Rating: Up to 0.1 W
- Operating Voltage: 75 V
- Insulation Resistance: > 10^6 Ω
- Operating Temperature Range: -55°C to +155°C
- Case Size: 0603 (RR1608M)
- Material: Thick film, high pulse performance design
- RoHS Compliant: Yes
- AEC-Q200 Qualified: Yes
- Packaging: Carrier tape, suitable for surface mounting
- Marking: Resistance value and tolerance
- Max Pulse Power: Valid for pulse durations in microseconds range
- Reliability: Stability AR/R < 1% over 1000 hours at 70°C
Buy the Vishay Series High Power Pulse Resistor: CRCW06035R60JNEAIF
Purchase the Vishay Series Pulse Resistor CRCW06035R60JNEAIF online today to secure a high pulse withstand capability up to 10 kW, perfect for demanding electronic circuits. Its compact 0603 case offers excellent surface-mount suitability. Engineered for stability, this resistor provides less than 1% AR/R resistance drift over 1000 hours at 70°C, making it ideal for circuits requiring high reliability under pulsed conditions. Enjoy fast delivery and expert support by ordering now to ensure your projects perform with dependable high power resistance.
Order your Vishay Series High Power Pulse Resistor CRCW06035R60JNEAIF today and enhance your electronic designs with reliable, high pulse energy performance.
