Vishay M8340107K1002GGD03 Resistor Network
The M8340107K1002GGD03 is a high-reliability military-grade thick film resistor network qualified under MIL-PRF-83401, suitable for demanding industrial, communications, and aerospace applications. It features epoxy molded construction, hot-solder dipped leads, and is available in various resistance values with TCR options of +100 ppm/°C or +300 ppm/°C. Designed for use in challenging environments, it ensures durability, stability, and consistent performance with full MIL-STD-202 testing, making it ideal for precise circuit applications requiring rugged, dependable resistor networks.
Vishay M8340107K1002GGD03 Resistor Network Specifications:
- Body Material: Epoxy molded construction
- Lead Finish: Hot-solder dipped leads
- Resistance Range: 1KΩ to 33KΩ, 1MΩ options available
- Resistance TCR: +100 ppm/°C (K) or +300 ppm/°C (M)
- Maximum Operating Voltage: 100 V
- Dielectric Strength: 200 V min
- Operating Temperature Range: -55°C to +125°C
- Storage Temperature Range: -55°C to +150°C
- Insulation Resistance: 10,000 MΩ minimum
- Mechanical: Pin spacing and dimensions per MIL specifications; epoxy body
- Environmental: Full MIL-STD-202 testing including resistance to soldering heat and thermal shock
- Packaging: Available in tube pack, dual-in-line molded DIP
- Impedance Codes: Various options from 82 Ω to 3.3 KΩ resistance values
- Reliability: 100% screen tested; meets military standards for durability and performance
Buy the Vishay M8340107K1002GGD03 – Reliable Resistor Network for Industrial Applications
Order the Vishay M8340107K1002GGD03 resistor network today and benefit from durability, precise resistance, and MIL-qualified standards. Perfect for military, aerospace, and industrial circuits, this epoxy-molded resistor network guarantees stability and reliability under extreme conditions. Its epoxy construction and full MIL-STD-202 testing make it a trusted choice for critical applications requiring rugged components. Shop online now to ensure your designs meet the highest standards of performance and durability efficiently.
Buy Vishay M8340107K1002GGD03 now and experience unmatched reliability and high performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy Vishay M8340107K1002GGD03?
You can click on the BUY or RFQ button to purchase M8340107K1002GGD03 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part M8340107K1002GGD03?
You can download the M8340107K1002GGD03 datasheet or visit the Vishay website for support.
Who is the manufacturer of M8340107K1002GGD03?
Vishay
