Vishay MAL205646103E3 Electrolytic Capacitors
These are high-reliability aluminum electrolytic capacitors designed for industrial applications, power supplies, and energy storage systems. They feature long useful life of up to 12,000 hours at 85°C, low ESR, high ripple current capacity, and pressure relief on top for safety. Suitable for smoothing, filtering, and pulse energy storage with robust construction including insulated cylindrical aluminum cases and pressure relief mechanisms. Compliance with RoHS and environmental standards makes them ideal for diverse industrial environments requiring dependable performance and durability.
Vishay MAL205646103E3 Electrolytic Capacitors Specifications:
- Nominal case size: 22x25 to 35x50 mm
- Rated capacitance range: 470 µF to 47,000 µF
- Tolerance on capacitance: ±20%
- Rated voltage range: 10V to 450V
- Category temperature range: -25°C to +85°C
- Endurance at 85°C: 5000 hours (up to 12,000 hours useful life)
- Useful life at 40°C: 210,000 hours at 1.4x Ip
- Shelf life at 0 V, 85°C: 500 hours
- Ripple voltage: up to 12V RMS
- Climatic category: IEC 60068 40/085/056
- Pressure relief on top case, pressure proof design
- RoHS compliant, non-solid electrolyte, blue insulated sleeve
- Maximum leakage current after 1 min at Up: ≤ 0.006 Ca × Un+4 μA
- Impedance scaled with frequency and temperature
- Maximum ESR and impedance at 100 Hz and 10 kHz
- Case dimensions and mounting holes designed for pinch-in snap-in mounting
Buy the Vishay Series 056/057 PSM-SI Reliable Electrolytic Capacitors for Industrial Applications
Purchase Vishay Series 056/057 PSM-SI aluminum electrolytic capacitors online today to ensure your industrial applications, power supplies, and energy storage systems benefit from reliable performance, long lifespan, and high ripple current capacity. With options available for various voltage and capacitance ratings, these capacitors offer low ESR, pressure relief safety features, and RoHS compliance. Securing them online guarantees fast delivery and premium quality for your engineering and manufacturing needs, making your projects safer and more efficient.
Order your Vishay Series 056/057 PSM-SI electrolytic capacitors today and give your projects the dependable quality they deserve for long-lasting power and filtering performance.
Frequently Asked Questions
Where can I buy Vishay MAL205646103E3?
You can click on the BUY or RFQ button to purchase MAL205646103E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL205646103E3?
You can download the MAL205646103E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL205646103E3?
Vishay
