Vishay MAL210118153E3 Power Aluminum Capacitor
High-performance, power aluminum electrolytic capacitors designed for high ripple current applications. Featuring screw terminals, durable aluminum case, and long useful life, these capacitors operate reliably at temperatures from -40°C to +85°C. Suitable for buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies, they provide high ripple current capacity, low ESR, and robust construction compliant with RoHS standards. Availability in various case sizes with specific electrical ratings ensures versatile integration in industrial and electronics equipment requiring stable, high-capacity energy storage with pressure relief features and temperature resilience.
Vishay MAL210118153E3 Power Aluminum Capacitor Specifications:
- Nominal case size: 35x60mm to 90x220mm
- Rated capacitance range: 220 LF to 1 F
- Tolerance on Capacitance: ±20%
- Rated voltage: 25 V to 450 V
- Category temperature range: -40°C to +85°C
- Endurance: 2000 to 10000 hours at 85°C depending on size
- Useful life: up to 400,000 hours at 85°C (for larger sizes), 10,000 hours at 40°C
- Shelf life: 500 hours at 0 V, 85°C
- RoHS compliant, non-solid electrolyte, pressure relief in sealing
- Maximum ripple current multiplier: 2.6 times at specific conditions
- Maximum surge voltage: 1.15× Un for U ≥ 50 V, 1.1× Un for U < 50 V
- Leakage current < 0.002 Cr at 5 mins at Un
- Maximum ESR at 100Hz: specified according to size
- Maximum impedance at 20kHz: specified according to size
- Case D: 35mm to 90mm with screw terminal configurations
- Maximum torque for screw terminals: 2 Nm (M5), 2.5 Nm (M6)
Buy the Vishay Series PHR-High Power Aluminum Capacitors: MAL210118153E3
Order Vishay power aluminum electrolytic capacitors with screw terminals online today to ensure high ripple current capacity and long operational life. These robust aluminum case capacitors operate reliably from -40°C to +85°C, making them ideal for buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies. They feature pressure relief in the sealing, RoHS compliance, and various size options with specific electrical ratings, providing superior performance in industrial and electronic applications. Purchase online now for fast delivery, secure payment, and expert support to meet your high-power needs.
Get Vishay MAL210118153E3 today—built for high ripple current, reliability, and long-lasting durability.
