Vishay MAL215099112E3 Aluminum Electrolytic Capacitor
The MAL215099112E3 is a high-reliability, surface-mount aluminum electrolytic capacitor designed for demanding industrial, automotive, and telecom applications. Featuring a rated capacitance of 4700 µF and a voltage of 35 V, it offers low impedance, high ripple current capacity, and extended useful life of up to 10,000 hours at 105°C. The capacitor supports high-temperature reflow soldering per JEDEC standards, ensuring reliable mounting in automated assembly processes. Its compact size and RoHS compliance make it suitable for smoothing, filtering, and buffering in compact electronic systems.
Vishay MAL215099112E3 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 4700 µF
- Rated Voltage: 35 V
- Case Size: 16x16x16 mm
- Temperature Range: -55°C to +105°C
- Endurance: up to 10,000 hours at 105°C
- Ripple Current: high ripple current capacity at 100 kHz
- Impedance: low impedance for high ripple applications
- RoHS compliant and suitable for high-temperature reflow soldering
- Leakage Current: < 0.01 x Ca x Ur after 2 min at Up
- Maximum ESR at 100 Hz: specified for each model
- Dissipation Factor: low tan δ at 100 Hz and 20°C
- Suitable for smoothing, filtering, buffering in industrial, automotive, telecom electronics
- Support advanced soldering profiles according to JEDEC J-STD-020, ensuring robust mounting
- Meets IEC 60384-18 / CECC 32300 standards, with long useful life and shelf life capabilities
Buy the Vishay Series CRZ Aluminum Electrolytic Capacitor: MAL215099112E3
Upgrade your electronic designs today by ordering the Vishay Series CRZ aluminum electrolytic capacitor MAL215099112E3 online. This high-performance capacitor offers a rated capacitance of 4700 microfarads and a voltage of 35 volts, ensuring optimal filtering and buffering in demanding industrial and automotive applications. Designed for high-temperature reflow soldering, RoHS compliance, and extended lifespan up to 10,000 hours at 105°C, it guarantees reliability and efficiency. Shop now to secure fast delivery and trusted quality for your projects.
Order your Vishay Series CRZ aluminum electrolytic capacitor MAL215099112E3 today and enhance your electronics with reliable, high-temperature performance.
