Vishay MAL219366151E3 Aluminum Electrolytic Capacitors
Vishay BCcomponents' aluminum electrolytic capacitors are compact, high ripple current devices designed for power inverters, motor controls, SMPs, and industrial applications. They feature improved ripple current capability, long useful life of 5000 hours at 105°C, and are available up to 500 V. Designed with polarized, non-solid electrolyte technology, these capacitors ensure high reliability, climatic resilience, and RoHS compliance. They are suitable for smoothing, filtering, and high ripple current scenarios in various industrial and renewable energy systems.
Vishay MAL219366151E3 Aluminum Electrolytic Capacitors Specifications:
- Nominal case size: 22x25 to 35x60 mm
- Rated capacitance: 47 UF to 820 UF
- Tolerance: +20%
- Rated voltage: 400 V to 500 V
- Category temperature range: -40°C to 105°C
- Endurance test: 2000 hours at 105°C
- Useful life: 5000 hours at 105°C
- Shelf life: 1000 hours at 0 V, 105°C
- Dimensions: 22x25 mm, 25x30 mm, up to 35x60 mm
- Ripple current capacity: high, specified at 100 Hz and 105°C
- Leakage current: < 0.01 Ca x Un after 5 min
- Impedance: Max 1.3 x specified at 100 Hz
- ESR: Typical 0.69 to 3.27 mΩ depending on size and voltage
- Maximum surge voltage: > 400 V Us = 1.1 Up
- Material: Polarized aluminum, non-solid electrolyte
- Certifications: RoHS compliant
Buy the Vishay Series PUR-SI Aluminum Electrolytic Capacitors: MAL219366151E3
Experience the reliability and high performance of Vishay PUR-SI aluminum electrolytic capacitors, perfect for power inverters, motor controls, and filtering. With ratings up to 820 UF and voltages up to 500 V, these capacitors offer long life of 5000 hours at 105°C. Their compact design, high ripple current capacity, and RoHS compliance make them ideal for industrial, renewable energy, and power supply applications. Purchase online today to ensure your projects benefit from proven durability and exceptional quality.
Get Vishay PUR-SI aluminum electrolytic capacitors today—built for high ripple current and long-lasting reliability in industrial power systems.
Frequently Asked Questions
Where can I buy Vishay MAL219366151E3?
You can click on the BUY or RFQ button to purchase MAL219366151E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL219366151E3?
You can download the MAL219366151E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL219366151E3?
Vishay
