Vishay P13LFL472MAB10 Sealed Potentiometer
The fully sealed cermet potentiometer offers high power handling of 1.5 W at 70°C and is suitable for military and professional applications requiring stability and precision. It features RoHS compliance, tight temperature coefficient of approximately 75 ppm/°C, and adheres to IEC standards. The robust design includes a sealed case, mechanical strength, and variable resistance options with linear and logarithmic tapers, making it ideal for controlling circuits in demanding environments. The potentiometer is available in multiple panel cutout sizes with optional sealing and shaft locking accessories, ensuring durability and reliability.
Vishay P13LFL472MAB10 Sealed Potentiometer Specifications:
- Power rating: 1.5 W at 70°C
- Resistance range: 1kΩ to 2.2MΩ
- Resistance tolerance: +20% (standard), +10% to +5% on request
- Resistance tapers: Linear and logarithmic
- Power handling: 0.75 W (logarithmic taper) at 70°C
- Temperature coefficient: Approx. 75 ppm/°C
- Mechanical travel: 300° ± 5°
- End resistance: Typical 10 Ω
- Dielectric strength: 2000 V RMS
- Insulation resistance: ≥10 MΩ at 300 VDC
- Sealing: Fully sealed IP67
- Operating temperature range: -55°C to +125°C
- Terminal material: Pure Sn
- Mechanical torque: Nominal 2.85 oz.in (80 g·cm)
- Mounting nut torque: Max 22.4 Ib.in (2.0 Nm)
Buy the Buy Vishay Sfernice Fully Sealed Cermet Potentiometer Part Number P13LFL472MAB10 Online
Purchase the Vishay Series P13LFL472MAB10 fully sealed cermet potentiometer online today. Its high power rating of 1.5 W at 70°C, combined with robust sealing, mechanical strength, and precise resistance control, makes it ideal for demanding military and professional applications. With optional sealing between the bushing and front panel, and shaft locking accessories, it offers durability and flexibility for control circuits requiring high stability over temperature and environmental conditions. Order now for reliable, high-performance circuit control solutions.
Order your Vishay SeriesP13LFL472MAB10 sealed cermet potentiometer today and ensure your projects benefit from high stability and reliable performance.
