Vishay PRV6SAABJYB25102KA Sealed Potentiometer
The PRV6 series are fully sealed potentiometers designed for precision control in electronic applications, featuring high power ratings of 1.5 W at 70°C for cermet types and 0.75 W for conductive plastic types. They conform to CECC 41000 and IEC 60393-1 standards, ensuring reliable performance and long mechanical endurance of 50,000 cycles. The compact design includes both panel-sealed and fully sealed variants, with various shaft diameters, bushings, and mounting options. Ideal for industrial, instrumentation, and automation systems requiring durable, precise, and sealed potentiometers that endure harsh environments with high stability.
Vishay PRV6SAABJYB25102KA Sealed Potentiometer Specifications:
- Power Rating at 70°C: 1.5 W for cermet, 0.75 W for conductive plastic
- Electrical Travel: 270° + 15°
- Resistance Range: 470Ω to 1 MΩ (non-linear taper), 20.2 to 10 MΩ (linear taper)
- Resistance Tolerance: ±10%, ±5% (on request), ±20% standard
- Mechanical Travel: 300°
- Operating Torque: 0.7 to 3 oz.in
- End Stop Torque: 3 oz.in
- Tightening Torque: 13 oz.in
- Temperature Range: -55°C to +125°C
- Climatic Category: 55/125/56
- Sealing: Fully sealed container and panel sealed with O-ring
- Dielectric Strength: 1750 Vrms
- Insulation Resistance: >10^9 Ω at 500 VDC
- Shock Resistance: 3 shocks in 3 axes, 0.1% max variation
- Vibration Resistance: 7s cycle, ±0.1% variation
- Environmental Durability: 50,000 cycles mechanical endurance, damp heat, and thermal stability tests
- Limits of Voltage: 350V
- Contact Resistance Variation: <2%
- End Resistance: Typical 1Ω
Buy the Buy Vishay PRV6 Series Fully Sealed Potentiometer Part Number PRV6SAABJYB25102KA Online
Purchase the Vishay PRV6 series fully sealed potentiometer online today for dependable, long-lasting performance in industrial, instrumentation, and automation applications. Designed for durability, these potentiometers feature high power ratings, excellent environmental sealing, and long mechanical endurance of 50,000 cycles. Available in various shaft sizes, sealing options, and resistance ranges, they are ideal for demanding settings requiring precise adjustment and reliable operation under harsh conditions. Ensure your projects benefit from top-quality control components accessible with fast online ordering.
Order your Vishay PRV6SAABJYB25102KA series sealed potentiometer today and ensure reliable, durable control in harsh environments.
