Vishay RCWE2512R820FKEA Low Resistance Chip Resistor
These low resistance thick film surface mount chip resistors are highly sulfur resistant and RoHS compliant, available in various sizes including 0402, 0603, 0805, 0612, 1206, 1210, 1020, 2010, and 2512. They feature enhanced power ratings, lead (Pb)-free solder contacts, and are suitable for current sensing and shunt applications. These AEC-Q200 qualified resistors provide precise resistance values from 0.01 Ω to 0.976 Ω with tight tolerances of 0.5% or 1.0%, making them ideal for demanding electronic circuits requiring reliable low resistance components.
Vishay RCWE2512R820FKEA Low Resistance Chip Resistor Specifications:
- Resistance Range: 0.01 Ω to 0.976 Ω depending on model
- Power Ratings: varies by size, e.g., 0.125 W for 0402, 0.2 W for 0603, 0.5 W for 0805
- Resistance Tolerance: 0.5% and 1.0%
- Temperature Coefficient: typically 100 ppm/°C to 600 ppm/°C depending on model
- Operating Temperature Range: -55°C to +155°C
- Maximum Operating Voltage: varies by size, e.g., >75 V for 0402, >100 V for 0603
- Dimensions (mm): 0402 (1.0 x 0.5), 0603 (1.6 x 0.8), 0805 (2.0 x 1.25), 0612 (3.2 x 1.6), 1206 (3.2 x 1.6), 1210 (3.2 x 2.5), 1020 (4.0 x 2.0), 2010 (5.0 x 2.0), 2512 (6.3 x 3.2)
- Environmental Compliance: RoHS compliant, sulfur resistant per ASTM B809-95
- Qualification: AEC-Q200 qualified
- Material: High-quality ceramic with protective overglaze
- Lead Solder Contacts: Lead (Pb)-free on Ni barrier layer
Buy the Vishay Series RCWE2512 Low Resistance Chip Resistor: RCWE2512R820FKEA
Discover the high-performance low resistance chip resistors ideal for current sensing and shunt applications, offered in multiple sizes with sulfur resistance and RoHS compliance. Suitable for demanding electronic designs, these resistors feature precise resistance values from 0.01 Ω to 0.976 Ω, tight tolerances, and robust construction. With enhanced power ratings and high-quality ceramic materials, they ensure reliable operation across a wide temperature range. Purchase online today for fast delivery and dependable performance in your electronic assemblies.
Order your Vishay Series RCWE2512 low resistance chip resistor today and ensure reliable current sensing in your electronics projects.
Frequently Asked Questions
Where can I buy Vishay RCWE2512R820FKEA?
You can click on the BUY or RFQ button to purchase RCWE2512R820FKEA from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part RCWE2512R820FKEA?
You can download the RCWE2512R820FKEA datasheet or visit the Vishay website for support.
Who is the manufacturer of RCWE2512R820FKEA?
Vishay
