Vishay SB350E354 Schottky Barrier Rectifier
The Vishay SB350E354 is a high-speed Schottky barrier rectifier with a maximum repetitive peak reverse voltage of 50 V and a forward current of 3.0 A. Featuring a small conduction loss, rapid switching capabilities, and a guardring for overvoltage protection, it is ideal for low-voltage, high-frequency applications such as inverters, DC/DC converters, and polarity protection circuits. The device comes in a DO-201AD package with RoHS compliance, solderable leads, and a high surge capability, ensuring reliability in demanding electronic environments.
Vishay SB350E354 Schottky Barrier Rectifier Specifications:
- Maximum repetitive peak reverse voltage: 50 V
- Maximum RMS voltage: 35 V
- Maximum DC blocking voltage: 50 V
- Average forward rectified current: 3.0 A
- Forward voltage drop: 0.49 V at 3.0 A
- Maximum instantaneous forward voltage: 0.68 V
- Peak surge current: 120 A
- Operating junction temperature range: -65 to +125 °C
- Storage temperature range: -65 to +150 °C
- Package: DO-201AD
- RoHS compliant, solderable leads, glass passivated chip
- Thermal resistance junction to lead: 30 °C/W
- Material: Molding compound meets UL 94 V-0
Buy the Buy Vishay SB350E354 Part Number SB350E354 Online
Purchase the Vishay SB350E354 Schottky Barrier Rectifier online for high-speed, low-loss power conversion in your circuits. Designed for low-voltage, high-frequency applications such as inverters and DC/DC converters, it features a maximum repetitive peak reverse voltage of 50 V, a forward current of 3.0 A, and a low forward voltage drop of 0.49 V. The device's RoHS compliance, fast switching capability, and robust construction ensure reliable operation and efficient power management. Order now to enhance your circuit performance with this dependable rectifier.
Get Vishay SB350E354 today—built for fast switching and reliable power rectification.
Frequently Asked Questions
Where can I buy Vishay SB350E354?
You can click on the BUY or RFQ button to purchase SB350E354 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part SB350E354?
You can download the SB350E354 datasheet or visit the Vishay website for support.
Who is the manufacturer of SB350E354?
Vishay
