WURTH ELEKTRONIK 2614011037000 GNSS Receiver Module
The GAL-BDS GNSS module is a compact, high-precision GPS and GLONASS receiver designed for reliable satellite navigation in industrial applications. It features an integrated patch antenna, a fast Time To First Fix within 28 seconds, and supports multiple GNSS constellations including GPS, GLONASS, Galileo, and BeiDou. Operating at 3.3 V with a low power consumption of 31 mA during tracking, it offers an accuracy of approximately 15 meters. Suitable for use in harsh environments with an operating temperature range up to +85°C, making it ideal for navigation, tracking, and positioning systems requiring high sensitivity and accuracy.
WURTH ELEKTRONIK 2614011037000 GNSS Receiver Module Specifications:
- Antenna Connector Type: Integrated Patch
- Rx Sensitivity (Tracking): -165 dBm
- Rx Sensitivity (Acquisition): -148 dBm
- Frequency: Min 1560 MHz, Max 1620 MHz
- Input Frequency at 1575.42 MHz
- Impedance: 50 Ω
- Return Loss RL: G aB
- Communication Protocol: UART
- Current Consumption: 31 mA during tracking, 33 mA during power mode
- Supply Voltage: 3.3 V, operating range from 2.6 V to 4.5 V
- Position Accuracy (GPS & GLONASS): Circular Error 15 m (50%), 25 m (GPS only)
- Time to First Fix (Cold Start): approx. 28 seconds
- Operating Temperature: -40°C to +85°C
- Storage Conditions: <40°C, <90% RH
- Moisture Sensitivity Level: MSL 3
- RoHS and REACH compliant
- Supports GNSS constellations: GPS, GLONASS, Galileo, BeiDou
Buy the Wirth Elektronik GAL-BDS GNSS – Reliable Satellite Navigation for Industrial Applications
Enhance your projects with the Wirth Elektronik GAL-BDS GNSS receiver module, offering high accuracy, multi-constellation support, low power consumption, and durable performance. Its integrated patch antenna ensures reliable satellite reception, enabling precise positioning for industrial navigation, tracking, and mapping solutions. Operating efficiently within a temperature range up to +85°C, it is ideal for demanding environments. Easy to integrate via UART interface, this module ensures long-term stability and adherence to safety standards. Purchase online today for dependable satellite positioning to elevate your applications' performance.
Order your Wirth Elektronik GAL-BDS GNSS module today and enhance your navigation and tracking systems with precise, reliable satellite positioning.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 2614011037000?
You can click on the BUY or RFQ button to purchase 2614011037000 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 2614011037000?
You can download the 2614011037000 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 2614011037000?
WURTH ELEKTRONIK
