WURTH ELEKTRONIK 430156050726 THT Relay
The Wurth Elektronik 430156050726 is a THT relay designed for general electronics applications. It boasts a compact form factor, a stainless steel cover for durability, and a LCP frame. Key specifications include a contact resistance of 100mOHM initially and 2OHM after life testing, an insulation resistance of over 100MOHM, and a dielectric strength of 250VAC. It's crucial to consult with Wurth Elektronik for applications requiring high safety and reliability, such as aerospace or medical devices. The relay is compliant with RoHS and REACH standards, ensuring environmentally responsible usage.
WURTH ELEKTRONIK 430156050726 THT Relay Specifications:
- Rating: 50mA, 12VDC
- Contact Resistance: 100mOHM max (initial), 2OHM max (after life test)
- Insulation Resistance: min. 100MOHM at 500VDC
- Dielectric Strength: 250VAC for 1 minute
- Stroke: 0.25 + 0.2 mm / - 0.1 mm
- Cover Material: Stainless Steel
- Stem Material: LCP UL 94V-0
- Frame Material: LCP UL 94V-0, color Black
- Contact Material: Stainless Steel with silver cladding
- Terminal Material: Brass with tin plating
- Wave Soldering Temperature: 260°C 10sec. max
- Hand Soldering Temperature: 350°C for 3 sec. max
- Storage Temperature: -40°C ~ +85°C
- Operation Temperature: -40°C ~ +85°C
- Compliance: Lead Free, ROHS, Reach
Buy the 430156050726 WURTH ELEKTRONIK THT Relay | myMectronic
Purchase the Wurth Elektronik 430156050726 THT Relay securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 430156050726?
You can click on the BUY or RFQ button to purchase 430156050726 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 430156050726?
You can download the 430156050726 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 430156050726?
WURTH ELEKTRONIK
