WURTH ELEKTRONIK 431183015816 SMT Tact Switch
The WS-TASV J-Bend SMT Tact Switch is a compact 5x5 mm electronic switch featuring a ground terminal for enhanced grounding and reliable operation. Designed for general electronic equipment, it offers a high mechanical operation force of 160 g ±50g and an electrical life of 1,000,000 cycles. Made with copper alloy, stainless steel, and polyimide tape, it endures operating temperatures from -40°C to +85°C. Suitable for various applications requiring dependable switching with minimal actuation force and robust construction, this switch is ideal for compact, high-reliability electronic designs.
WURTH ELEKTRONIK 431183015816 SMT Tact Switch Specifications:
- Dimensions: 5x5 mm footprint with ground terminal
- Height H: 1.5 mm
- Material: Copper Alloy, Stainless Steel, Polyimide tape
- Operating Temperature: -40°C to +85°C
- Operation Force: 160 g ±50 g
- Electrical Life: 1,000,000 cycles
- Rated Voltage: 15 V
- Rated Current: 20 mA
- Contact Resistance: Initial 100 mΩ max, After Life 2 Ω max
- Insulation Resistance: 100 MΩ min at 500 VDC
- Shock & Vibration: Compliant with standard testing requirements
- Soldering Profile: Preheat 150-200°C, Max Peak Temperature 260°C for reflow
Buy the Wurth Elektronik 431183015816 – Reliable SMT Tact Switch for Industrial Applications
Purchase the Wurth Elektronik SMT tact switch 431183015816 online today and equip your electronic devices with a dependable, durable, and high-performance switch. Ideal for compact applications, it features a ground terminal, excellent cycle life, and a temperature range of -40°C to +85°C. Easy to install with a 5x5 mm footprint, this switch ensures reliable operation in industrial, consumer, and automation electronics. Secure your supply and benefit from fast delivery, quality assurance, and expert support for your critical designs.
Order your Wurth Elektronik series 431183015816 SMT tact switch today and enhance your electronic projects with reliable performance and robust design.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 431183015816?
You can click on the BUY or RFQ button to purchase 431183015816 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 431183015816?
You can download the 431183015816 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 431183015816?
WURTH ELEKTRONIK
