WURTH ELEKTRONIK 62201621821 Dual Socket Connector
The Wurth Elektronik WR-PHD THT Straight Dual Socket is a high-reliability, gold-plated, stamped contact header designed for use in electronic circuit assemblies. With a pitch of 1.27 mm and a length of 10.16 mm, it supports up to 16 pins and withstands 500 mating cycles. Its UL94 V-0 rated insulator is black, made from PAST material, suitable for applications requiring durable, vibration-resistant connectors. Certified RoHS and UL approved, it is ideal for standard and safety-critical electronic devices requiring secure, precise connections with 85-90 words. The connector is used in general electronics, with careful handling needed to ensure long-term performance.
WURTH ELEKTRONIK 62201621821 Dual Socket Connector Specifications:
- Pitch: 1.27 mm
- Number of Pins: 16
- Pin to Pin (Middle): 8.89 mm
- Length: 10.16 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Contact Type: Stamped
- Insulator Material: PAST
- Insulator Flammability Rating: UL94 V-0
- Operating Temperature: -40 up to +105 °C
- Working Voltage: 100 VAC
- Withstanding Voltage: 500 V (AC) for 1 min
- Contact Resistance: Max 20 mΩ
- Insulation Resistance: Min 1000 MΩ
- Durability: 500 mating cycles
- Certification: RoHS, UL (322964)
Buy the Wurth Elektronik Series WR-PHD Connector: 62201621821
Purchase the Wurth Elektronik WR-PHD dual socket connector online to ensure a secure, reliable connection in your electronic projects. Featuring a 1.27 mm pitch and gold-plated contacts, this component supports up to 16 pins and withstands 500 mating cycles. Its UL94 V-0 rated insulator is made from durable PAST material, offering excellent thermal and electrical performance. Certified RoHS and UL compliant, it’s ideal for standard electronics and safety-critical applications. Order now for fast delivery and guaranteed quality in your manufacturing or repair tasks.
Get Wurth Elektronik WR-PHD 62201621821 today—built for precision, durability, and reliable electronic circuit connections.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 62201621821?
You can click on the BUY or RFQ button to purchase 62201621821 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 62201621821?
You can download the 62201621821 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 62201621821?
WURTH ELEKTRONIK
