WURTH ELEKTRONIK 638307122002 Male Right Angled Header
The Würth Elektronik WR-FAST 638307122002 is a male right-angled header designed for general electronic equipment. It features a 7.62mm pitch, 2 pins, and tin-plated contacts, ensuring reliable connections. This header is RoHS compliant and suitable for various applications requiring secure and efficient power distribution. It is not intended for use in safety-critical applications without proper evaluation and agreement. The header's robust design and tin plating provide excellent corrosion resistance and long-term reliability in a wide range of electronic assemblies.
WURTH ELEKTRONIK 638307122002 Male Right Angled Header Specifications:
- Pins: 2
- Length L: 11.74 mm
- Operating Temperature: -30 up to +120 °C
- Rated Current: 16 A
- Working Voltage: 300 V (AC)
- Insulation Resistance: 5 MΩ
- Withstanding Voltage: 1600 V (AC)
- Contact Resistance: 20 mΩ
- Insulator Material: PC
- Insulator Flammability Rating: UL94 V-0
- Contact Material: Steel
- Contact Plating: Tin
- Contact Type: Stamped
- Durability: 500 Mating cycles
- Pitch P: 7.62 mm
- RoHS Approval: Compliant [ 2011/65/EU&2015/863 ]
- REACh Approval: Conform or declared [ (EC)1907/2006 ]
- Glow Wire Approval: Compliant [ IEC 60335-1 ]
- cULus Approval: E150931 [ Cat.N° : CQQ, CQS(3) ]
