WURTH ELEKTRONIK 65503503515301 RF SMA Connector
This SMA straight plug is designed for flexible RG58 cable connections, offering reliable RF signal transfer with high durability and excellent shielding characteristics. Manufactured with brass components and gold-plated contacts, it ensures optimal electrical performance up to 1 GHz impedance of 50Ω. Suitable for applications demanding high reliability, it features a passivated stainless steel retention ring, silicone gasket, and a black heat shrink tube for insulation. The connector is RoHS compliant and engineered for secure, stable connections in telecommunications and electronic systems.
WURTH ELEKTRONIK 65503503515301 RF SMA Connector Specifications:
- Connector Type: SMA straight plug
- Cable Type: Flexible RG58
- Center Contact Material: Brass with Gold plating
- Impedance: 50Ω
- Frequency Range: DC to 1 GHz
- VSWR: 1.3 max at DC to 1 GHz
- Insertion Loss: 0.19 dB max at DC to 1 GHz
- Insulation Resistance: 1000 MΩ at 500 V DC for 120 seconds
- Withstanding Voltage: 500 V (AC) for 60 seconds, 1000 V (AC) minimum
- Operating Temperature: -20°C to +80°C
- Mechanical Mating Cycles: 500
- Body Material: Brass with gold plating, passivated stainless steel retention ring
- Gasket Material: Silicone, color red
- Ferrule Material: Brass with gold plating
- Heat Shrink Tube: PE, color black
- Dimensions: Consistent with standard SMA connectors for reliable fit
- Compliance: RoHS
Buy the Buy Wirth Elektronik SMA Straight Plug Part Number 65503503515301 Online
Enhance your RF systems with the reliable Wirth Elektronik SMA Straight Plug, designed for flexible RG58 cables. Featuring gold-plated contacts and brass construction, it provides low VSWR and high durability. Ideal for communication equipment, testing, and measurement setups, the connector ensures secure connections with a maximum frequency of 1 GHz. Its RoHS compliance and robust design make it suitable for professional and industrial applications. Purchase online now to benefit from fast delivery and secure checkout, ensuring your projects have top-quality components for optimal performance.
Order your Wirth Elektronik SMA Straight Plug with RG58 cable compatibility today and ensure stable, high-quality RF connections for your electronic projects.
