WURTH ELEKTRONIK 744325120 Power Choke Coil
The WURTH ELEKTRONIK WE-HCI 744325120 power choke coil is a critical component in various electronic applications, including DC-DC converters, power supplies, and filtering circuits. Its design prioritizes efficient energy storage and minimizes energy loss. The coil's specifications, such as inductance, DC resistance, and saturation current, are carefully engineered to meet the demands of modern electronic systems. The component's robust construction and adherence to industry standards ensure reliable performance and longevity in a wide range of industrial environments. It is suitable for applications requiring high current handling and efficient filtering.
WURTH ELEKTRONIK 744325120 Power Choke Coil Specifications:
- A: 10.5± 1.0 mm
- B: 10.2± 0.5 mm
- C: 4.7± 0.3 mm
- D: 2.2± 0.5 mm
- E: 4.00 ± 0.1 mm
- F: 2.00 ± 0.1 mm
- G: 1.75 ± 0.1 mm
- Lerrlaufinduktivität: 1.20 µH @ 100 kHz / 0.1A
- Nenn-Induktivität: 1.00 µH @ 100 kHz / 0.1A / 20A
- DC-Widerstand: 1.80 mΩ @ 20° C
- Nennstrom: 20.0 A @ ∆T= 50 K
- Sättigungsstrom: 25.0 A @ ∆L/L0= 30 %
- Eigenres.-Frequenz: 65 MHz
- Initial Inductance: 1.20 µH
- Rated Inductance: 1.00 µH
- DC Resistance: 1.80 mΩ
- Rated Current: 20.0 A
- Saturation Current: 25.0 A
- Self-Resonant Frequency: 65 MHz
- a: 11.3 ± 0.1 mm
- b: 16.0 ± 0.1 mm
- c: + 0.1 mm
- d: + 0.05 mm
- H: 11.5 ± 0.1 mm
- I: 10.8 ± 0.1 mm
- J: 5.40 ± 0.1 mm
- T: 0.35 ± 0.05 mm
- W: 24.0 ± 0.3 mm
