WURTH ELEKTRONIK 861141484011 Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for electronic applications requiring high reliability and safety standards. It features a capacitance of 150 pF rated at 450 V (DC), with an operating temperature range of -25°C to +105°C. Suitable for general electronic equipment, it provides a maximum ripple current of 880 mA at 105°C. The capacitor is RoHS and REACH compliant, with dimensions of 25.0 x 36.0 mm, and is engineered for long life with a load life of 3000 hours at 105°C. It includes safety vents and is suitable for use in power supplies and filtering circuits.
WURTH ELEKTRONIK 861141484011 Electrolytic Capacitor Specifications:
- Capacitance: 150 pF
- Rated Voltage: 450 V (DC)
- Operating Temperature Range: -25°C to +105°C
- Load Life: 3000 hours at 105°C
- Dimensions: 25.0 x 36.0 mm
- Leakage Current: 779.42 pA max after 5 min
- Ripple Current: 880 mA at 105°C
- Dissipation Factor (120 Hz): 20% typ.
- Storage Conditions: 35°C, <45% RH
- Polarity: Anode marked and sleeve with negative terminal
- Safety features: Vent for pressure relief, explosion-proof design
- RoHS & REACH compliant, designed for electronic power applications
Buy the Wurth Elektronik 861141484011 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase the Wurth Elektronik aluminum electrolytic capacitor online today for your industrial power and filtering needs. This high-quality component offers a capacitance of 150 pF rated at 450 V, with an operating temperature range of -25°C to +105°C. It features long load life, a safety vent, high ripple current capacity, and complies with RoHS and REACH standards. Designed for reliable performance in power supplies and electronic systems, this capacitor ensures stability and safety in demanding environments. Order now for quick delivery and optimal circuit performance.
Get Wurth Elektronik 861141484011 today—built for power stability and long-lasting durability in demanding electronic applications.
