WURTH ELEKTRONIK 744340300055 High Current Flat Inductor
The Würth Elektronik WE-HCM series is a shielded SMT power inductor designed for high-current applications. These inductors offer a compact form factor and excellent electrical performance, making them ideal for DC-DC converters, power management circuits, and other demanding applications. They are characterized by a low DC resistance, which minimizes power losses, and a high self-resonant frequency, which ensures efficient operation over a wide frequency range. The RoHS compliant and halogen-free design aligns with environmental regulations. Operating temperatures range from -40°C to +125°C, and the component is marked with a date code for traceability.
WURTH ELEKTRONIK 744340300055 High Current Flat Inductor Specifications:
- Inductance L: 0.055 µH ±15%
- Rated Inductance LR: 0.055 µH typ.
- Rated Current IR: 27 A max.
- Saturation Current ISAT: 24 A typ.
- DC Resistance RDC: 0.27 mΩ ±15%
- Self Resonant Frequency fres: 123 MHz typ.
- Ambient Temperature: -40 up to +85 °C
- Operating Temperature: -40 up to +125 °C
- Moisture Sensitivity Level (MSL): 1
- Packaging Quantity: 2000
- Material: Polystyrene
Buy the 744340300055 WURTH ELEKTRONIK High Current Flat Inductor | myMectronic
Purchase the Würth Elektronik 744340300055 High Current Flat Inductor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 744340300055?
You can click on the BUY or RFQ button to purchase 744340300055 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 744340300055?
You can download the 744340300055 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 744340300055?
WURTH ELEKTRONIK
