WURTH ELEKTRONIK 7447669182 High Frequency SMD Inductor
The WE-GFH High Frequency SMD Inductor by Wurth Elektronik is designed for use in electronic circuits requiring high-frequency inductance. It features a compact size, high self-resonant frequency, and low DC resistance, making it suitable for RF and microwave applications. The inductor has a rated current of 300 mA and operates within ambient temperatures of -40°C to +85°C, with a maximum operating temperature of 125°C. Compliant with RoHS and REACh standards, it is ideal for automated SMT assembly and high-frequency circuit designs.
WURTH ELEKTRONIK 7447669182 High Frequency SMD Inductor Specifications:
- Inductance: 0.82 μH at 0.975 MHz ±10%
- Rated current: 300 mA at 40K Ik
- DC Resistance: 3.10 mΩ @ 20°C, max 3.18 mΩ @ 20°C
- Self resonant frequency: 11 MHz
- Q-factor: 40 min at 0.975 MHz
- Operating temperature: -40°C to +125°C
- Ambient temperature: -40°C to +85°C
- Storage temperature (tape & reel): -20°C to +60°C, 75% RH max
- Reflow Profile: max ramp-up 3°C/sec, peak temperature 245°C, max time within 5°C of peak 20-30 sec
- Size: 4532
- Compliance: RoHS & REACh
Buy the Wurth Series High Frequency SMD Inductor: 7447669182
Shop the Wurth Series High Frequency SMD Inductor online now and ensure optimal performance in RF and microwave circuits. Perfect for automated SMT assembly, this RoHS-compliant inductor offers low DC resistance, high self-resonant frequency, and robust thermal stability. Designed for precise inductance and reliable operation, it is ideal for various high-frequency electronic applications. Order today to benefit from fast delivery, competitive pricing, and trusted quality assurance for your critical electronic designs.
Get Wurth Series High Frequency SMD Inductor 7447669182 today—built for high-frequency RF applications with reliable performance and durability.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 7447669182?
You can click on the BUY or RFQ button to purchase 7447669182 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 7447669182?
You can download the 7447669182 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 7447669182?
WURTH ELEKTRONIK
