WURTH ELEKTRONIK 749013011A LAN transformer
The LAN Transformer WE-LAN PoE by WURTH ELEKTRONIK is a high-quality network component designed for Power over Ethernet applications such as 10/100Base-TX. It features robust electrical properties including inductance at 100kHz, a turns ratio of approximately 1:3, and low insertion loss from 1 to 100MHz for optimal signal transmission. The transformer is made from ferrite with copper wire contacts, operating reliably between -40°C and +105°C. Its compact design, UL94-VO rated case, and high-voltage tests ensure durability and safety under various conditions, compatible with IEEE 802.3af/at standards and auto-MDIX functionality.
WURTH ELEKTRONIK 749013011A LAN transformer Specifications:
- Base Material: Ferrite
- Wire: Copper Ni-Sn plated
- Operating Temperature Range: -40°C to +105°C
- Dimensions: 24.00 +0.1 mm x 11.50 +0.1 mm x 11.42 +0.1 mm
- Inductance: 350 μH min at 100kHz / 100mV
- Turns Ratio: 1 Tx to 3 Rx (±3%)
- Insertion Loss: 1.1 dB max at 1-100 MHz
- Return Loss: ≥33 dB at 50 MHz
- Differential Mode Rejection: -38 dB at 60 MHz
- Crosstalk: ≥35 dB at 700 MHz
- Voltage Rating: 1500 Vrms hipot withstand for 1 min.
- Certifications: UL94-VO, RoHS compliant
- Mechanical: 10-100 BaseT PoE compatible, dimensions suitable for PCB integration
- Test Conditions: Humidity 33%, ambient temperature +25°C, tested with HP-4284 and HP-8714
Buy the WURTH ELEKTRONIK Series LAN-Transformer: 749013011A
Get the WURTH ELEKTRONIK LAN transformer designed specifically for reliable Power over Ethernet connections in your network systems. This high-quality component ensures excellent signal transmission with low insertion loss, high immunity to noise, and compatibility with IEEE 802.3af/at standards. Its compact size, UL94-VO flame rating, and robust electrical properties make it ideal for industrial, commercial, or networking applications. Purchase online today to enhance your network's performance and security with proven components from WURTH ELEKTRONIK.
Order your WURTH ELEKTRONIK Series LAN-Transformer 749013011A today and ensure your network systems feature durable, reliable PoE connectivity.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 749013011A?
You can click on the BUY or RFQ button to purchase 749013011A from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 749013011A?
You can download the 749013011A datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 749013011A?
WURTH ELEKTRONIK
