WURTH ELEKTRONIK 860130674004 Aluminum Electrolytic Capacitor
The WURTH ELEKTRONIK WCAP-ATET aluminum electrolytic capacitor is a robust component designed for a wide range of general electronic applications. With a capacitance of 47µF and a rated voltage of 50V, it provides reliable power storage and filtering capabilities. The capacitor operates effectively within a temperature range of -40°C to +125°C, making it suitable for demanding environments. Proper polarity must be maintained during operation to ensure optimal performance and prevent damage. This capacitor is not intended for use in safety-critical applications without thorough evaluation and agreement with Würth Elektronik.
WURTH ELEKTRONIK 860130674004 Aluminum Electrolytic Capacitor Specifications:
- Dimensions_a: 8.0 mm
- Dimensions_b: 3.5 mm
- Dimensions_L: 11.5 mm
- Dimensions_t: 1.5 mm
- Pin_Diameter: 0.5 mm
- Pin_Spacing_P: 3.5 mm
- Pin_Diameter_a: 0.8 mm
- Capacitance: 47 µF
- Rated_Voltage_UR: 50 V (DC)
- Leakage_Current_ILeak: 23.5 μA
- Dissipation_Factor_DF: 10 %
- Ripple_Current_Iripple: 140 mA
- Operating_Temperature: -40 °C bis +125 °C
- Storage_Conditions: 35°C, <45% RH
- Load_Life: 1000 h @ +125°C / 50 V (DC)
- Multiplier_for_Ripple_Current_60Hz: 0.80
- Multiplier_for_Ripple_Current_120Hz: 1.00
- Multiplier_for_Ripple_Current_400Hz: 1.30
- Multiplier_for_Ripple_Current_1000Hz: 1.45
- Multiplier_for_Ripple_Current_10000Hz: 1.65
- Multiplier_for_Ripple_Current_50000_100000Hz: 1.70
- Preheat_Temperature_Min_Tsmin: 100 °C
- Preheat_Temperature_Typical_Tstypical: 120 °C
- Preheat_Temperature_Max_Tsmax: 130 °C
- Preheat_Time_ts: 70 seconds
- Delta_Preheat_to_Max_Temperature: 150 °C max.
- Peak_Temperature_Tp: 250 °C - 260 °C
- Time_of_Actual_Peak_Temperature_tp: max. 10 seconds
- Ramp_down_Rate_Min: ~ 2 K/s
- Ramp_down_Rate_Typical: ~ 3.5 K/s
- Ramp_down_Rate_Max: ~ 5 K/s
- Time_25C_to_25C: 4 minutes
