WURTH ELEKTRONIK 860130678009 Aluminum Electrolytic Capacitor
The WCAP-ATET series from Würth Elektronik is a range of aluminum electrolytic capacitors designed for general electronic equipment applications. These capacitors provide reliable performance with a capacitance of 330µF and a rated voltage of 50V. Key electrical properties include a dissipation factor of 10% (typical), a ripple current capability of 810mA, and a leakage current of 165µA. The capacitors are suitable for a wide range of applications where stable capacitance and voltage handling are required. Always observe correct polarity during operation and refer to the datasheet for detailed specifications and operating conditions. Würth Elektronik emphasizes that these components are not intended for use in safety-critical applications without proper evaluation and agreement.
WURTH ELEKTRONIK 860130678009 Aluminum Electrolytic Capacitor Specifications:
- A Dimensions (mm): D ±0.5: 5.0, P ±0.5: 20.0, L ±t: 13.0, t: 1.5, Pin Ø ±0.02: 0.6, a: 5.0, b: 0.9
- Capacitance: 330 µF
- Rated Voltage (V DC): 50
- Leakage Current (μA): 165
- Dissipation Factor (%): 10 (typical)
- Ripple Current (mA): 810 @ 120Hz @ 125°C
- Operating Temperature (°C): -40 to +125
- Storage Conditions: 35°C, <45% RH
- Load Life (h): 2000 @ +125°C / 50 V (DC)
- Component Marking - 1st Line: Capacitance value: 330 µF & Rated voltage: 50 V (DC)
- Component Marking - 2nd Line: WCAP-ATET & max. operating temperature +125°C
- Component Marking - 3rd Line: Datecode: YWW
- Component Marking - 4th Line: VENT marking
- Multiplier for Ripple Current vs. Frequency (C ≤ 10): 0.80
- Multiplier for Ripple Current vs. Frequency (10 < C ≤ 100): 0.90
- Multiplier for Ripple Current vs. Frequency (100 < C ≤ 1000): 0.10
- Multiplier for Ripple Current vs. Frequency (1000 < C): 0.11
- Preheat Temperature Min (°C): 100
- Preheat Temperature Typical (°C): 120
- Preheat Temperature Max (°C): 130
- Preheat Time (seconds): 70
- Peak Temperature (°C): 250 - 260
- Peak Time (seconds): max. 10
- Ramp-down Rate (K/s): ~2 - ~5
Buy the 860130678009 WURTH ELEKTRONIK Aluminum Electrolytic Capacitor | myMectronic
Purchase the WURTH ELEKTRONIK 860130678009 Aluminum Electrolytic Capacitor securely and conveniently online.
Buy Now
