WURTH ELEKTRONIK 860241375001 Aluminum Capacitor
Würth Elektronik aluminum electrolytic capacitor model WCAP-AT1H is designed for electronic equipment requiring reliable power filtering and energy storage under high temperature conditions. It features a rated voltage of 400 V, capacitance of 6.8 μF with a tolerance of +20%, and operates effectively within -25°C to +105°C. The capacitor has a corrosion-resistant aluminum case with a PVC sleeve, a vent for pressure relief, and is suitable for load life of 10,000 hours at 105°C. Its construction ensures high safety and durability in industrial applications.
WURTH ELEKTRONIK 860241375001 Aluminum Capacitor Specifications:
- Capacitance: 6.8 μF + 20% tolerance
- Rated Voltage: 400 V DC
- Operating Temperature Range: -25°C to +105°C
- Load Life: 10,000 hours at 105°C
- Leakage Current: max. 208.8 μA after 1 min.
- Dissipation Factor: 120Hz, 20%
- Ripple Current Multiplier: 0.5 at 120Hz, 0.8 at 1000Hz, 0.85 at 10kHz, 1.0 at 100kHz
- Size: 10.0 x 12.5 mm
- Vent for pressure relief, aluminum case with PVC sleeve
- Maximum peak temperature during soldering: 250°C - 260°C for max 10 seconds
- Soldering: Wave soldering from PCB underside, avoid direct contact with body
- Storage Condition: 5°C to 35°C, <75% RH
- Electrical Properties tested at 20°C, 33% RH
- Compliance: RoHS & REACH
Buy the Wurth Elektronik 860241375001 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Order the aluminum electrolytic capacitor from Würth Elektronik now to ensure high-quality power filtering and energy storage solutions for industrial applications. With a capacitance of 6.8 μF and a voltage rating of 400 V, this capacitor offers durability and reliable performance from -25°C to +105°C. Its robust aluminum case with vent ensures safety under high temperature and electrical stress, making it ideal for power supplies, filtering circuits, and energy storage in complex industrial systems. Purchase online for quick delivery and expert support.
Buy Würth Elektronik 860241375001 now and experience unmatched reliability and performance for power filtering and energy storage in your industrial projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 860241375001?
You can click on the BUY or RFQ button to purchase 860241375001 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 860241375001?
You can download the 860241375001 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 860241375001?
WURTH ELEKTRONIK
