WURTH ELEKTRONIK 865230243003 Electrolytic Capacitor
Würth Elektronik's WCAP-AS5H aluminum electrolytic capacitor is designed for electronic applications requiring stable capacitance, low leakage current, and high reliability. With a capacitance of 47 μF ±20% and a rated voltage of 10 V, it performs well in power supply circuits, filtering, and energy storage. It handles temperatures from -40°C to +105°C and offers a load life of 5000 hours at 105°C. The compact size 6.3 x 5.5 mm makes it ideal for space-constrained designs in electronic, industrial, and communication equipment.
WURTH ELEKTRONIK 865230243003 Electrolytic Capacitor Specifications:
- Capacitance: 47 μF ±20%
- Rated Voltage: 10 V
- Leakage Current: 47 μA max. after 2 min.
- Dissipation factor: 28% typ. at 120Hz
- Ripple Current: 48 mA max. at 100kHz and 105°C
- Operating Temperature: -40°C to +105°C
- Load Life: 5000 hours at 105°C/10 V
- Size: 6.3 x 5.5 mm
- Shelf Storage Conditions: 35°C, <45% RH
- Test Conditions: 20°C, 33% RH
Buy the Buy Würth Elektronik Aluminum Electrolytic Capacitor Part Number 865230243003 Online
Boost your electronic designs with Würth Elektronik’s high-quality aluminum electrolytic capacitor. With a capacity of 47 microfarads and a maximum voltage of 10 volts, it ensures stable operation from -40°C to +105°C. Its compact size of 6.3 x 5.5 mm makes it perfect for space-constrained applications like power supplies, filtering, and energy storage in industrial and communication devices. Enjoy quick delivery and secure online purchase to keep your projects running efficiently and reliably.
Order your Würth Elektronik WCAP-AS5H aluminum electrolytic capacitor today and enhance your electronic projects with reliable capacity and superior performance.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865230243003?
You can click on the BUY or RFQ button to purchase 865230243003 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865230243003?
You can download the 865230243003 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865230243003?
WURTH ELEKTRONIK
