WURTH ELEKTRONIK 861111485026 Electronic Capacitor
These are aluminum electrolytic capacitors designed for electronic equipment requiring stable capacitance and voltage handling. Theyoperate within -25°C to +105°C, featuring a rated voltage of 450V DC and capacitance of 180μF with a tolerance of ±20%. Suitable for power smoothing, filtering, and energy storage applications, these capacitors have a long load life of 2000 hours at 105°C, with low leakage current of 1620pA. They include a vent for pressure relief and are RoHS & REACh compliant, ideal for industrial and electronic circuit applications.
WURTH ELEKTRONIK 861111485026 Electronic Capacitor Specifications:
- Capacitance: 180 μF ±20%
- Rated Voltage: 450 V DC
- Leakage Current: 1620 pA max after 5 min
- Dissipation Factor: 20% at 120Hz
- Ripple Current: 990 mA max at 105°C
- Operating Temperature: -25°C to +105°C
- Load Life: 2000 hours at 105°C
- Storage Conditions: 35°C, <45% RH
- Case Size: 30.0 x 26.0 mm
- Polarity: Negative terminal marked, vent for pressure relief
- RoHS & REACh compliant
- Soldering: Wave soldering according to instructions
- Sealing Material: PVC sleeve resistant to heat and solvents
- Application: Power filtering, energy storage, industrial electronics
- Design: Long-life aluminum electrolytic specify for stable electrical performance
Buy the WURTH ELEKTRONIK 861111485026 – Reliable Capacitors for Industrial Applications
Secure your projects with the high-quality aluminum electrolytic capacitors from WURTH ELEKTRONIK, rated at 450V DC and 180μF, suitable for demanding industrial electronics. Featuring a long load life of 2000 hours at 105°C, low leakage current, and RoHS & REACh compliance, these capacitors ensure reliable operation in power smoothing, filtering, energy storage, and other critical applications. Easy to install, with a pressure relief vent and robust design, order online today to enhance your electronic systems with proven durability and performance.
Buy WURTH ELEKTRONIK 861111485026 now and experience unmatched reliability and performance in your power and filtering applications.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 861111485026?
You can click on the BUY or RFQ button to purchase 861111485026 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 861111485026?
You can download the 861111485026 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 861111485026?
WURTH ELEKTRONIK
