WURTH ELEKTRONIK 865230357007 Aluminum Capacitor
Würth Elektronik's aluminum electrolytic capacitor offers reliable performance with a capacitance of 330 μF ±20% and a rated voltage of 16 V. Designed for general electronic applications, it features a maximum temperature of +105°C and a long load life of 5000 hours. The capacitor is suitable for smoothing, filtering, and energy storage in electronic circuits with stable electrical properties, leakage current of 52.8 μA max, and dissipation factor of 22%. Its robust construction ensures durability and efficient operation in a variety of electronics including power supply units and industrial equipment.
WURTH ELEKTRONIK 865230357007 Aluminum Capacitor Specifications:
- Capacitance: 330 μF ±20%
- Rated Voltage: 16 V
- Temperature Range: -40°C to +105°C
- Load Life: 5000 hours @ +105°C
- Leakage Current: 52.8 μA max.
- Dissipation Factor: 22% typ.
- Ripple Current: 300 mA max at 100kHz and 105°C
- Dimensions: 10.0 x 10.5 mm
- Material: Aluminum oxide dielectric with electrolyte
- Polarity: Polarity marked; observe correct orientation
- RoHS and REACH compliant
- Storage Conditions: 5°C to 35°C and less than 75% RH
Buy the Würth Elektronik 865230357007 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase Würth Elektronik aluminum electrolytic capacitor today for reliable performance in power supplies, filtering, and energy storage. With a capacitance of 330 μF and rated voltage of 16 V, it offers a long life of 5000 hours and operates from -40°C to +105°C. Its robust design ensures stable electrical properties, low leakage current, and high ripple current handling. Ideal for industrial, consumer, and electronic equipment, this capacitor guarantees durability and efficient operation, making it an essential component for professional and technical applications.
Get Würth Elektronik 865230357007 today—built for durability and stable energy storage in industrial electronics.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865230357007?
You can click on the BUY or RFQ button to purchase 865230357007 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865230357007?
You can download the 865230357007 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865230357007?
WURTH ELEKTRONIK
