WURTH ELEKTRONIK 865230640006 Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for general electronic applications, offering 2.2 µF capacitance with a 50 V rated voltage and operating temperature of -40°C to +105°C. It has a load life of 5000 hours at 105°C/50 V, with low leakage current and dissipation factor of 12%. Suitable for power supplies and electronic circuits, it features a compact 4.0 x 5.5 mm size, equipped with a vent for safety, and complies with RoHS and REACH standards. Ideal for durable, high-reliability electronic systems in industrial and consumer devices.
WURTH ELEKTRONIK 865230640006 Electrolytic Capacitor Specifications:
- Capacitance: 2.2 µF + 20%
- Rated Voltage: 50 V
- Leakage Current: 3 HA max after 2 min
- Dissipation Factor: 12% typ at 120 Hz
- Ripple Current: 100kHz@105°C, ripple 1 mA max
- Operating Temperature: -40°C to +105°C
- Load Life: 5000 hours @ +105°C/50 V (OC)
- Size: 4.0 x 5.5 mm
- Polarity: Marked on top, negative terminal with semicircle
- Storage Conditions: 5°C to 35°C, <75% RH
- Soldering: Reflow profile with peak at 217°C, preheat 150°C-200°C, max ramp rates 3°C/sec up, 6°C/sec down
Buy the Wurth Elektronik 865230640006 – Reliable Electrolytic Capacitor for Industrial Applications
Purchase the Wurth Elektronik electrolytic capacitor now to ensure durability and stability in your electronic projects. With a capacitance of 2.2 µF and a rated voltage of 50 V, it operates efficiently within a temperature range of -40°C to +105°C. Its load life of 5000 hours makes it ideal for long-term applications. The compact size 4.0 x 5.5 mm allows flexible placement on circuit boards. RoHS and REACH compliant, it guarantees safety, environmental standards, and high performance for industrial, consumer, and electronic equipment.
Get Wurth Elektronik 865230640006 today—designed for high reliability in power supplies and electronic circuits.
