WURTH ELEKTRONIK 870235174005 Aluminum Polymer Capacitor
WURTH ELEKTRONIK WCAP-PT5H Aluminum Polymer Capacitors are high-performance, compact capacitors designed for electronic circuits requiring reliable energy storage and filtering. Suitable for general electronic applications, these capacitors operate over a temperature range of -55°C to +105°C. They feature a capacitance of 820 μF with a rated voltage of 6.3 V DC, low ESR, and high ripple current capacity. Ideal for power supplies, smoothing, and decoupling tasks, they ensure stable operation under varied conditions, with a design optimized for durability and safety in electronic systems.
WURTH ELEKTRONIK 870235174005 Aluminum Polymer Capacitor Specifications:
- Capacitance: 820 μF + 20%
- Rated Voltage: 6.3 V DC
- Operating Temperature: -55°C to +105°C
- Leakage Current: 516.6 HA max after 2 minutes
- Dissipation Factor: 10 % typ at 120 Hz
- Ripple Current: 6100 mA max at 105°C and 100 kHz
- Dimensions: 8.0 x 11.5 mm
- Storage Conditions: 5°C to 35°C, <75% RH
- Load Life: 5000 hours at +105°C/6.3 V
- Soldering: Wave and hand soldering compatible with specified procedures
- Polarity: Marked negative terminal; risk of damage if reversed
- Environmental: Not for high safety or hazardous environments, avoid exposure to halogenated solvents, xylene, or UV radiation
Buy the Buy WURTH ELEKTRONIK Aluminum Polymer Capacitor Part Number 870235174005 Online
Purchase WURTH ELEKTRONIK Aluminum Polymer Capacitors Part Number 870235174005 online to benefit from their high energy storage capacity, low ESR, and robust performance across a wide temperature range. These capacitors are ideal for power supply filtering, smoothing, and decoupling applications in electronic circuits requiring durable, high-reliability components. Enjoy fast delivery, secure checkout, and expert support to complement your electronic manufacturing or repair projects with dependable, high-quality capacitors tailored for modern electronic demands.
Order your WURTH ELEKTRONIK Series WCAP-PT5H Aluminum Polymer Capacitor today and ensure reliable energy storage for your electronic projects.
