WAGO 20041304 3-conductor Terminal Block
The WAGO 2004-1304 is a robust 3-conductor through terminal block engineered for demanding industrial environments, particularly those requiring Ex safety. Utilizing WAGO’s Push-in CAGE CLAMP® connection technology, it ensures reliable and secure connections for conductors ranging from 0.5 to 6 mm². The block is designed for mounting on DIN rails (35 x 15 and 35 x 7.5) and is suitable for applications requiring high voltage and current carrying capacity, such as power distribution and control systems in hazardous areas. Its blue color and side/center marking options facilitate easy identification and organization within electrical panels.
WAGO 20041304 3-conductor Terminal Block Specifications:
- Nominal Voltage (III/3): 800 V
- Rated Surge Voltage (III/3): 8 kV
- Rated Current: 32 A
- Rated Current 2: 41 A
- Ratings per IEC/EN: IEC/EN 60947-7-1
- Rated Voltage UL (Use Group B): 600 V
- Rated Current UL (Use Group B): 30 A
- Rated Voltage UL (Use Group C): 600 V
- Rated Current UL (Use Group C): 30 A
- Rated Voltage CSA (Use Group B): 600 V
- Rated Current CSA (Use Group B): 30 A
- Rated Voltage CSA (Use Group C): 600 V
- Rated Current CSA (Use Group C): 30 A
- Ratings per ATEX: PTB 05 ATEX 1095 U / IECEx: PTB 05.0033U (Ex eb IIC Gb)
- Rated Voltage EN (Ex e II): 550 V
- Rated Current (Ex e II): 30 A
- Connection Technology: Push-in CAGE CLAMP®
- Actuation Type: Push-in
- Connectable Conductor Materials: Copper
- Nominal Cross-section: 4 mm²
- Solid Conductor: 0.5 … 6 mm² / 20 … 10 AWG
- Solid Conductor; Push-in Termination: 1.5 … 6 mm² / 14 … 10 AWG
- Fine-stranded Conductor: 0.5 … 6 mm² / 20 … 10 AWG
- Fine-stranded Conductor; with Insulated Ferrule: 0.5 … 4 mm² / 20 … 12 AWG
- Fine-stranded Conductor; with Ferrule; Push-in Termination: 1.5 … 4 mm² / 18 … 12 AWG
- Strip Length: 11 … 13 mm / 0.43 … 0.51 inch
- Total Number of Connection Points: 3
- Total Number of Potentials: 1
- Number of Levels: 1
- Wiring Type: Front-entry wiring
- Number of Jumper Slots: 2
- Width: 6.2 mm / 0.244 inch
- Height: 65.5 mm / 2.579 inch
- Depth from Upper Edge of DIN-rail: 32.9 mm / 1.295 inch
- Design: horizontal type
- Mounting Type: DIN-35 rail
- Marking Level: Center/side marking
- Color: blue
- Insulation Material: Polyamide (PA66)
- Fire Load: 0.15 MJ
- Weight: 8.4 g
- Product Group: 22 (TOPJOB S)
- Packaging Type: BOX
- Country of Origin: DE
- GTIN: 4017332071550
- Customs Tariff Number: 85369010000
