WAGO 20911422 2-pole Angled Header
The WAGO 2091-1422 is a 2-pole male header featuring angled solder pins and a 3.5mm pin spacing. This header is ideal for applications requiring vibration resistance, thanks to its shrouded design. It allows for flexible functionality through the use of compatible female connectors, enabling different functions to be divided within a single header. Coding pins prevent mismating and allow for subsequent coding in panel feedthrough applications. Suitable for a wide range of industrial automation and control systems, this header offers reliable performance and ease of integration.
WAGO 20911422 2-pole Angled Header Specifications:
- No. of Poles: 2
- Color: light gray
- Overvoltage category EN 1: III
- Pollution degree (1): 2
- Rated voltage EN (1) [V]: 160
- Rated surge voltage (1) [kV]: 2.5
- Nominal current [A]: 10
- Overvoltage category EN 2: II
- Degree of pollution (2): 2
- Rated voltage EN (2) [V]: 320
- Bemessungsstossspannung (2) [kV]: 2.5
- Nominal current (2) [A]: 10
- Overvoltage category EN 3: III
- Degree of pollution (3): 3
- Rated voltage EN (3) [V]: 160
- Rated surge voltage (3) [kV]: 2.5
- Nominal current (3) [A]: 10
- Solder pin length [mm]: 3.6
- Solder pin diameter [mm]: 1
- Drilled hole diameter [mm]: 1.2
- Tolerance of drilled hole diameter [mm]: +0.1
- Material group: I
- Insulating material: Polyphtalamide glass fiber (PPA-GF)
- Flammability rating per UL 94: V0
- Lower limit temperature [C]: -60
- Upper temperature limit [C]: 100
- Contact material: Electrolytic copper (Ecu)
- Contact plating: tin-plated
- Fire load [MJ]: 0.022
- Weight [g]: 0.99
- Width [mm]: 9
- Width [in]: 0.354
- Height [mm]: 12.4
- Height [in]: 0.488
- Length [mm]: 17.5
- Length [in]: 0.689
- Pin spacing from [mm]: 3.5
