WAGO 2231102026000 2-pole Female Connector
The WAGO 2231-102/026-000 is a 2-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It offers a universal connection for all conductor types and simplifies wiring with its push-button design, eliminating the need for specialty tools. The ability to wire while mated enhances efficiency, and integrated test ports allow for parallel conductor testing. This connector is ideal for applications requiring reliable and easy-to-use connections in industrial environments. It is important to note that this connector does not have breaking capacity and should not be connected/disconnected when live or under load.
WAGO 2231102026000 2-pole Female Connector Specifications:
- conductor_size: 0.2 … 2.5 mm² / 24 … 12 AWG
- pin_spacing: 5 mm
- pole_number: 2
- material: Polyamide (PA66)
- flammability_class: V0
- rated_voltage_iii_3: 320 V
- rated_surge_voltage_iii_3: 4 kV
- rated_current: 16 A
- voltage_ul_use_group_b: 300 V
- current_ul_use_group_b: 15 A
- packaging_type: BOX
- country_of_origin: PL
- gtin: 4045454696399
- customs_tariff_number: 85366990990
- operating_temperature: -60 … +100 °C
- width: 11.5 mm
- height: 15 mm
- depth: 25.6 mm
- weight: 3.4 g
