WAGO 231112037000 Female Connector 12 Pole
The WAGO 231-112/037-000 is a high-quality female connector designed for use in various industrial applications. This 12-pole connector features a locking lever for secure connections, integrated fixing flanges for easy mounting, and coding fingers for positive identification. It is suitable for applications requiring reliable power and signal transmission in control cabinets, machinery, and automation systems. The CAGE CLAMP® connection ensures a gas-tight connection with minimal effort, while the robust design provides long-lasting performance. It is compatible with a wide range of wire gauges and offers excellent electrical characteristics, making it a versatile solution for diverse industrial needs.
WAGO 231112037000 Female Connector 12 Pole Specifications:
- Product Group: Multi Conn. System
- Weight: 23.07 g
- Color: gray
- No. of Connection Points: 12
- No. of Potentials: 12
- Pole Count: 12
- Height: 14.3 mm
- Height (in): 0.563 in
- Width: 76.6 mm
- Width (in): 3.016 in
- Depth: 29.6 mm
- Depth (in): 1.165 in
- Pin Spacing From: 5 mm
- Pin Spacing From (in): 0.197 in
- Pollution Degree: 2
- Measured Voltage EN: 320 V / 630 V
- Measured Shock Voltage: 4 kV
- Current Intensity EN: 16 A
- Connection Method: CAGE CLAMP® CONNECTION
- Cross Section Solid [mm²]: 0.08 - 2.5
- Cross Section [mm²]: 0.25 - 1.5
- Cross Section [AWG]: 28 - 12
- Strip Length From: 8 mm
- Strip Length To: 9 mm
- Material Group: xxx-xxx/035-000
- ABS Approval: 04-HG469925/1-PDA
- BV Approval: 11915/A0
- CCA Approval: 5764
- CSA Approval: 154112-1466354
- GL Approval: 17296-00HH
- KEMA Approval: 2083746.02
- KR Approval: HMB05880-EL003
- LR Approval: 91/20112(E3)
- RMR Approval: 11130002
- UR Approval: E45171
- UR Approval 2: E45172
Buy the 231-112/037-000 WAGO Female Connector 12 Pole | myMectronic
Purchase the WAGO 231-112/000 securely and efficiently through our online store.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231112037000?
You can click on the BUY or RFQ button to purchase 231112037000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231112037000?
You can download the 231112037000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231112037000?
WAGO
