WAGO 231204026000 4 Pole Female Plug Connector
The WAGO 231-204/026-000 is a robust 4-pole female plug connector ideal for various industrial applications requiring secure and efficient power distribution. Its cage clamp connection technology simplifies wiring and reduces installation time, while the integrated fixing flanges provide mechanical stability. The connector's coding fingers prevent incorrect connections, enhancing system reliability. Suitable for applications in control cabinets, machinery, and automation systems, this connector offers a dependable solution for connecting power and signal lines.
WAGO 231204026000 4 Pole Female Plug Connector Specifications:
- Packing Unit: 50 pieces
- Pin Spacing: 7.5 mm / 0.295 in
- Pole Count: 4
- Cross Section Range (mm²): 0.08 - 2.5
- Cross Section Range (AWG): 28 - 12
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage: 400 V
- Measured Shock Voltage: 6 kV
- Pollution Degree: 3
- Current Intensity: 16 A
- Weight: 8.3 g
- Color: grey
- No. of Connection Points: 4
- No. of Potentials: 4
- Height: 14.3 mm / 0.563 in
- Width: 29 mm / 1.142 in
- Depth: 26.45 mm / 1.041 in
- Strip Length: 8 - 9 mm / 0.33 in
- Approval Office (ABS): 04-HG469925-PDA
- Approval Office (BV): 11915/A0
- Approval Office (CCA): 5764
- Approval Office (CSA): 154112-1466354
- Approval Office (DEMKO): 88126
- Approval Office (GL): 17296-00HH
- Approval Office (KEMA): 2083746.02
- Approval Office (KR): HMB05880-EL003
- Approval Office (LR): 96/20035
- Approval Office (NEMKO): P94101840
- Approval Office (RMR): 11130002
- Approval Office (UR): E45172
Buy the 231-204/026-000 WAGO 4 Pole Female Plug Connector | myMectronic
Purchase the WAGO 231-204/026-000 securely and efficiently through our online store.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231204026000?
You can click on the BUY or RFQ button to purchase 231204026000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231204026000?
You can download the 231204026000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231204026000?
WAGO
